Environmental Simulation Test Machine

Name: Environmental Simulation Test Machine
Brand: ASLi
SKU: 110176119

US$ 5,000 - 50,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ASLi

Model Number:

Dongguan ASLi Test Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN/HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ASLi

Model Number TH

Power Other, Electronic, AC380V

Usage Universal Testing Machine

Environmental Simulation Test Machine

Environmental Simulation Test Machine Features

1.This temperature and humidity test chabmer with graceful appearance,circularly shaped body, surface treated

with mist strips, and plane handle with no reaction. Easy to operate, safe and reliable.

2.Rectangular doubleglassed watching window for the observation of the test production during the testing process.

The window is equipped with sweatproof electrical heating device that can prevent water steam from condensing into

droplets, and with high brightness PL fluorescent bulbs to provide light inside the box.

3.Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.

4.Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and

automatically recyclable.

5.The French Tecumseh brand is used for the circulation system of the compressor, capable of removing the lubricant

between the condensation pipes and capillaries. The environment protecting coolant is used for the whole series

(R23,R404A)

6.Imported LCD display screen is used for the control unit, capable of displaying the measured value as well as the set

value and time.

Environmental Simulation Test Machine Application:

Temperature and humidity test chamber is used to test various types of materials for their tolerances of heat, cold,dry,

humidity. It is applied for quality inspection for all types of electronic products, electric appliance,and products from

communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.

Environmental Simulation Test Machine Technical Parameters :

Model	F-TH-150(A~F)		F-TH-225(A~F)	F-TH-408(A~F)		F-TH-800(A~F)	F-TH-1000(A~F)
Internal Dimension WxHxD( mm)	500x600x500		600x750x500	600x850x800		1000x1000x800	1000x1000x1000
Internal Dimension WxHxD (mm)	1100x1750x1600		1200x1800x1700	1250x1900x1900		1600x2050x2150	1700x2200x2300
Range of Fast Temperature Change		Temperature Range: -70~+150ºC; Range of Fast Temperature Change: -45~+85ºC; Max. temperature rising/falling speed is 15ºC/min when the whole process with linear control .
Humidity Range(Optional)		20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is a special optional condition,need Dehumidifier)
Analytic Accuracy/Distribution Uniformity of Temperature and Humidity					0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H.
Control Accuracy ofTemperature and Humidity					±0.5ºC; ±2.5% R.H.
Temperature Rising/Falling Speed Rate			The Temperature Rising/Falling Speed Rate with linear control : 3~15ºC/min, adjustable The Temperature Rising/Falling Speed Rate non-linear control : 3~30ºC/min, adjustable
Internal and External Material			Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or SEE cold-rolled steel with paint coated.
Insulation Material			Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials
Cooling System			Water cooling/single segment compressor
Optional Accessories			Inner door with operation hole(Optional), Water Purifier, Dehumidifier
Compressor			French Tecumseh Brand, Germany Bizer Brand
Power			AC380V 3 ø 5 lines, 50/60HZ
