Xenon lamp climate resistant tester application:
Xenon Aging Weather Test Chamber is a comprehensive climate testing machine, it can do climatic aging test,and also can do fading acceleration test under color effect or color changed. The test range including: dying and finishing, printing, leather, plastic, plyglass, painting, textile, printing ink, rubber and also the industry relative color. Light fastness and fade grade can be known in short time. Those materials exposed at simulated sunlight to evaluated the material’s light fastness performance.
Xenon lamp climate resistant tester features:
1. Advanced design technology and concept,
2. Excellent technology of producing and outstanding system of quality management,
3. Xenon lamp tester can be the most realistic simulated solar spectrum, including ultraviolet,visible and infrared.
4. Be tested in the range of the full spectrum, necessary for most textile sun and color fastness test.
5. To determine the color fastness and aging to sunlight, weather resistance, etc.
Xenon lamp climate resistant tester technical parameters:
| Model | XL - 1000 | |
|
Internal Dimension WxHxD (mm) |
900x900x900 | |
|
External Dimension WxHxD (mm) |
1500x2000x1400 | |
| Tube Using Life (H) | 1500 | |
| Tube Power | 1KW/6KW | |
| Illumination intensity |
340nm 0.35~0.6w/m2 |
Full spectrum 1200±200w/m2 |
| Lighting Filter Type | Inner filter | Quartz |
| Outer filter | Quartz | |
| Simulated Test Status |
Test samples: Explore under outer space |
|
| Cooling System | Water cooling or wind cooling | |
|
Temperature Control Range of the Test Cabinet |
Black panel temperature : BPT 40~120℃(±3℃) | |
| Black standard temperature : BST 38~120℃(±3℃) | ||
|
Humidity Control Range of the Test Cabinet |
Humidity when lighting:20%R.H.~75%R.H. (± 5%R.H.) | |
| Humidity when dark :60%R.H.~95%R.H. (± 5%R.H.) | ||
|
Rotating Speed of the Samples Holder(RPM) |
1~5 adjustable | |
| Diameter of Sample Shelf(mm) | 500±50 | |
| Sunlight Exposure Cycle | 0.01~999 hours 59mins | |
| Raining Period/ Time | Raining Period:1~240mins,discontinuous-type, adjustable | |
| Raining Time:1~9999mins, adjustable, water spray pressure 70~130Kpa | ||
| Spray Water Flow (L/min) | 1~2.4 | |
| Explore Area(cm2) | 7500 | |
| Power | AC 380V, 50/60HZ , 3ph 5 Lines | |
Warranty: 1 year warranty for whole set.
Xenon lamp climate resistant tester Pictures:
