Home > Electrical & Electronics > Sensor > Pressure Sensor > Double Ended Shear Beam 20 Ton Alloy Steel Load Cell Sensor

Double Ended Shear Beam 20 Ton Alloy Steel Load Cell Sensor

Name: Double Ended Shear Beam 20 Ton Alloy Steel Load Cell Sensor
Brand: SILVANUS
SKU: 110202835

Double Ended Shear Beam 20 Ton Alloy Steel Load Cell Sensor thumbnail-1

Double Ended Shear Beam 20 Ton Alloy Steel Load Cell Sensor photo-1

US$ 89 - 150 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

SILVANUS

Model Number:

QSM

Contact Supplier Request Quote Chat Now

Silvanus Electric Manufacture (Yixing) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name SILVANUS

Model Number QSM

Usage Pressure Sensor

Theory Resistance Sensor

Output Analog Sensor

Double Ended Shear Beam Load Cell (QSM)(15t,20t)

QSM Load Cell Features

1.Bridge type double shear beam, unique floating bearing structure

2.Self-resetting,good side force resistance and shock resistance

3. Moisture-proof sealed , ideal for hostile environment

4.Simple to install , easy to use , good interchangeability

QSM Load Cell Application

truck scales,rail scales,bin and hopper scales,etc.

QSM Load Cell Dimensions(mm)

QSM Load Cell Specifications

Emax(Max. capacity)	t	15,20
Sensitivity	mV/V	2.0±0.002
Accuracy class		C2	C3
Maximum number of verification intervals	nmax	2000	3000
Minimum load cell verification interval	Vmin	Emax/5000	Emax/10000
Combined error	%F.S	≤±0.030	≤±0.020
Creep	%F.S/30min	≤±0.024	≤±0.016
Temperature effect on sensitivity	%F.S/10°C	≤±0.017	≤±0.011
Temperature effect on zero	%F.S/10°C	≤±0.023	≤±0.015
Zero balance	%F.S	±1.0
Input resistance	Ω	750±30Ω
Output resistance	Ω	702±3Ω
Service temperature range	°C	-30...+70
Safe overload	%F.S	150
Ultimate overload	%F.S	250
Recommended excitation voltage	V	5…15
Insulation resistance	MΩ/50V	>5000
Protection class		IP67
Load cell material		Alloy steel
Cable length	m	5,10m
Cable outer caliber	mm	Φ6

Packaging & Delivery

PACKAGE

Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.

Our Company:

Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
