Help CenterHot High Efficiency Cement Roller Press for Grinding
Related Products
-
High Quality Cement Mill Grinding MachineUS$ 880,000 - 3,670,000MOQ: 1 Set -
Super Quality Rotary Intermittent Ball Mill With Low CostUS$ 1,500 - 999,999MOQ: 1 Set
-
Professional Roller Heat Press With Muiti-functionsUS$ 130,000 - 2,000,000MOQ: 1 Set
-
Mining Cement Lab Ball MillUS$ 1,500 - 999,999MOQ: 1 Set
-
Energy Saving Ball Mill Machine for Russia MarketUS$ 1,500 - 999,999MOQ: 1 Set
Specifications
high efficiency cement roller press:1.Productivity: increase30%-40%;
2.Energy consumption: decrease20%-30%
3.Space-saving.
Brief introduction of high efficiency cement roller press :
This kind roller press for grinding is specially designed for grinding clinker and raw meal.
Features and Structures of high efficiency cement roller press :
1. Four row cylinder roller bearing with higher capacity.
2. The roller shaft can be solid forged, or of the structure of fixed bush. The roller surface is with advanced and proven technology, long service-life, and easy maintenance.
3. The self-aligning hydro-cylinder adopts the America Parker cylinder head, with long-term reliable operation.
4. The moving roller and fixed roller adopts technology from Germany KHD Co., with self-aligning sliding, stable stress, good damping effect, and assures the long-term stable operation.
5. Advanced intelligent lubrication system
6. Perfect program control system, highly integrated hydraulic system, all critical parts are imported parts.
7. The adjustable feeding system with electric actuator.
8. It is flexible to be equipped with imported or domestic planetary reducer and main bearing.
Working principle of high efficiency cement roller press :
Application of high efficiency cement roller press :
Technical parameter of high efficiency cement roller press :
| Model | DG1000×600 | DG1200×500 | DG1400×650 | DG1600×1000 |
| Diameter of roller(mm) | Φ1000 | Φ 1200 | Φ 1400 | Φ 1600 |
| Width of roller(mm) | 600 | 500 | 650 | 1000 |
| Max feeding size(mm) | 50 | 50 | 50 | 60 |
| Discharging size(after screening)(mm) | All≤4 80%≤2 30%≤0.08 | All≤4 80%≤2 30%≤0.08 | All≤4 80%≤2 30%≤0.08 | |
| Capacity (t/h) | 70-110 | 120-180 | 220-300 | 500-650 |
| Power(kw) | 110 | 250 | 630 | 1250 |
| Dimension(L×W×H) (mm) | 3840×3220×1720 | 4700×6485×2485 | 9200×6320×3600 | 10800×8100×4400 |
Showroom of high efficiency cement roller press
