Specifications
Spiral Classifier for mineral processing1.FLG series,ISO9001:2000
2.Sand Return 6-230t/h,Overflow 32-400t/h
Spiral classifier for ores upgrading,mineral processing,beneficiation from shanghai
1.Brief Introduction of Spiral Classifier
Spiral Classifier is widely used to control material size from Ball Mill in the beneficiation process, separate mineral
sand and fine mud in the gravity concentration, and clean mud and water in washing mineral process. This machine
has features of simple structure, reliable and convenient operation, etc.
2.Structure of Spiral Classifier:
We produce high weir type,single and double spiral,and immersed single and double spiral classifiers.The seat of
the machine features channel steel material,while the body is armor plated and the spiral axie is made of cast iron
for durability.The machine's lifting equipment can be classified as manually or electronically.
3.Application of Spiral Classifier:
Spiral classifier are widely used in the distribution of ore in closed-circuit with ball mill in mining processing,in order to get a certain degree fineness of ore particles,meanwhile
increasing the efficiency of grinding.This machine can also be used to washed sand classify ore sand and play
other functions.
4.Feature of Spiral Classifier:
This product features simple structure,reliable working conditions and convenient operation.
5.Principle of Spiral Classifier:
Different grains have different specific gravity and sedimentation rates in liquid,this product allows the fine ore to
flow in the water,while coarse ore sinks to the bottom.This classifier can filter materials and send coarse materials
to the feeding mouth and dischanrge fine materials from the pipe.
6.Types of Spiral Classifier
We have various of Spiral Classifier, such as FLG500, FLG750, FLG1000, FLG1200, FLG1500, GLG1800,FLG2000etc.
In order to give you a responsible quotation, you can inform us the following information:
1. What’s the material you are going to deal with?
2. What Spiral diameter do you want?
3. What’s the producing capacity you are going to achieve?
Our engineers will suggest you the most suitable one for you according to your information.
7.Technical parameters of Spiral Classifier
Model |
Spiral diameter(mm) |
Speed of Spiral |
capacity |
Slope (°) |
Power(KW) |
Weight (t) |
|
|
|
|
Sand Return (t/h) |
Overflow (t/h) |
|
|
|
FLG500 |
500 |
8-15.5 |
6-11 |
32 |
12-18 |
3 |
1.9 |
FLG750 |
750 |
4.5-10 |
11-24 |
65 |
12-18 |
3 |
2.7 |
FLG1000 |
1000 |
1.6-7.4 |
25-45 |
110 |
12-18 |
5.5 |
4.1 |
FLG1200 |
1200 |
5-7 |
50-80 |
155 |
12-18 |
5.5 |
7.5 |
FLG1500 |
1500 |
2.5-6 |
70-115 |
235 |
12-18 |
7.5 |
10.5 |
FLG1800 |
1800 |
2.5-6 |
100-190 |
310 |
12-18 |
11 |
17.1 |
FLG2000 |
2000 |
2.5-6 |
160-230 |
400 |
12-18 |
15 |
19.3 |
8.After-Sale Service:
Erection and Commissioning
Operator Training
Spare Parts Supply
Warranty Terms: More than 12 months
Delivery Time:25~30 days after receiving advanced payment
Products Certificate: TUVRheinland CE, ISO9001:2000
9.We(Shanghai LIPU Heavy Industry Co.,Ltd) believe that you can rely on us as we provide you quite satisfactory service and products with best quality at most competitive price in the world. We are very happy if you do not hesitate to send us any of your inquiries and we will always give satisfactory services.
Looking forward to hearing from you at your convenience!
