Specifications
Steel Coil Straightening Machine1. material width 400mm
2. material thick 0.35-3.2mm
can be design as your size
Dear Customers,
This is Ada,thanks for your interested in our products. The following is for your reference, we have our own design teams and factory ,we can design according to your requirement.Welcome your inquiry,I will reply you as soon as possible.
A.Commodity:HX series Steel Strip and Steel Coil Straightening Machine/Straightener
1. material width 400mm
2. material thick 0.35-3.2mm
3. speed 15m/min
This metal sheet straightening machine suit for any kinds and thickness of material straightening leveling.
B.Working principle and Composition
blanking line can arrange the shape automatically according to coil's width and coil's diameter,choice the best for shape. stamping line include recoiler,straightener unit,feeder,swing unit,mechanical press,stacking syetem,hydraulic system,electric control system.etc
C.Feature:
1. Suitable for straighten different thickness of metal sheets, and the material is very smooth after straightened by this model machine.
2. Equipped with Japan magnetic contactor and electronic components, minumin breakdown and long service life.
3. Efficient auto-feeding equipment, can be used individually, or work together with Auto Reel(MT type), Double Head Coil Cradle(MTD-type, MTDM-type) or Reel Stand(SCD-type), which can achive better productivity.
If you need more information,please feel free to contact me.I will do my best to help you.
Best wishes
Skype:adawei1019
Moibile:0086-13662169442
Model |
HX-150 | HX-200 | HX-300 | HX-400 | HX-500 | HX-600 | HX-700 | HX-800 | HX-1000 | HX-1300 | HX-1600 |
| HX-150A | HX-200A | HX-300A | HX-400A | HX-500A | HX-600A | HX-700A | HX-800A | HX-1000A | |||
| HX-150B | HX-200B | HX-300B | HX-400B | HX-500B | HX-600B | ||||||
| Material Width | 150 | 200 | 300 | 400 | 500 | 600 | 700 | 800 | 1000 | 1300 | 1600 |
| Material Thickness | 0.35-2.2 | 0.35-2.2 | 0.35-2.2 | 0.35-2.2 | 0.35-2.2 | 0.35-2.2 | 0.35-2.2 | 0.35-2.2 | 0.35-2.2 | 0.5-2.2 | 0.5-2.2 |
| 0.35-3.2 | 0.35-3.2 | 0.35-3.2 | 0.35-3.2 | 0.35-3.2 | 0.35-3.2 | 0.35-3.0 | 0.35-3.2 | 0.35-3.2 | |||
| 0.5-3.5 | 0.5-3.5 | 0.5-3.5 | 0.5-3.5 | 0.5-3.5 | 0.5-3.5 | ||||||
| Speed of Feed(m/min) | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Motor(hp) | 1/2 | 1 | 1 | 2 | 3 | 3 | 3 | 5 | 7.5 | 15 | 20 |
| 1 | 1 | 2 | 2 | 3 | 3 | 5 | 7.5 | 10 | |||
| 2 | 2 | 3 | 3 | 5 |
5 |
Hengxing Metallurgical Machinery Manufacturing CO.,LTD. has a history of more than 14 years in the steel equipment manufacturing industry,withtrust. an annual production of 60 sets of various types of equipment,400 tons of roll,the annual sales is RMB80,000,000. Our products are being sold to many countries ,such as Brazil in south america,Ukraine in eastern Europe,Kazakhstan,Kenya,India and some other countries.We have won overseas customer's trust.
