5A 8A Phocos Charge Controller Price Solar Charge Controller Solar Charge Controller CML

Name: 5A 8A Phocos Charge Controller Price Solar Charge Controller Solar Charge Controller CML
Brand: PHOCOS
SKU: 110442741

US$ 15 - 50 MOQ: 50 Pieces

Key Specifications

Place of Origin:

Germany

Brand Name:

PHOCOS

Model Number:

CML-02

Qingdao Commercial Energy Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Germany

Brand Name PHOCOS

Model Number CML-02

Application Solar System Controller

Rated Voltage 12V

Maximum Current 5A

Specifications

5A 8A phocos charge controller price solar charge controller solar charge controller CML
Intelligent Timer Functions
3years wa

5A 8A phocos charge controller price solar charge controller solar charge controller CML features

• Battery State-of-Charge display with 3 LEDs

• Acousticload disconnect pre-warning

• PWM-regulation(series type)

• Boost,Equalizeand Float charging, also for VRLA

• Automatic12/24 V detection

• Integratedtemperature compensation

• Largeterminals(up to 16 mm2 wire size)

• SOC and voltage controlled LVD

• Fully electronically protected

5A 8A phocos charge controller price solar charge controller solar charge controller CML specification

Type	CML 05	CML 08	CML 10	CML 15	CML 20
System voltage	12/24 V auto recognition
Max. charge/load current	5 A	8 A	10 A	15 A	20 A
Floatcharge	13.7/27.4 V (25 °C)
Boostcharge	14.4 /28.8 V (25 °C), 2 Std. activation: battery voltage < 12.3/24.6 V
Equalization	14.8/29.6 V (25 °C), 2 Std. activation: battery voltage < 12.1/24.2 V
Deep discharge protection: State of charge dependent Voltage dependent Reconnect level	11.4 – 11.9 V / 22.8 – 23.8 V 11.0/22.0 V 12.8/25.6 V
Overvoltage protection	15.5/31.0 V
Undervoltage protection	10.5/21.0 V
Max. panel voltage (Overvoltageprotection by varistor)	30 V in 12 V system 50 V in 24 V system
Temperaturecompensation (Charge voltage)	−25 mV/K at 12V −50 mV/K at 24V
Max. self consumption	< 4 mA
Grounding	positive grounding possible
Ambienttemperature	−40 to +50 °C
Max. height	4,000 m above sea level
Batterytype	lead acid (GEL, AGM, flooded)
Wire cross section	< 16 mm2
Weight	160 g
Dimensions (W x H x D)	80 x 100 x 32 mm
Type of protection	IP22
