Mobile Backup Power Supply

Name: Mobile Backup Power Supply
Brand: beyonderpower
SKU: 110520403

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

China

Brand Name:

beyonderpower

Model Number:

DBY40-48.220

Hangzhou Linan Beyonder Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai/hongkong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name beyonderpower

Model Number DBY40-48.220

Input Voltage 220V

Output Voltage 220V

Output Power 800W

Output Frequency 50±0.1%

Output Current 6.3A

Specifications

1.Easy To Carry
2.Green and Environment- Friendly
3.Easy To Operate

Main specifications

Technical specification		Datas	Range
Charger	Rated output voltage(Vdc)	48	44—57.6
	Rated output current(A)	5	0--5
	Anti-noise current sink	≤10%
	Input voltage(Vac)	220	100--265
	Input current(A)	1.5	0--8
AC OUTPUT	Capacity(VA)	1000VA	0—1500VA
	Output power(W)	800W
	Output voltage and frequency	220Vac 50HZ
	Rated output current(A)	6.3	8
	Output voltage accuracy(V)	220±5%
	Output frequency accuracy(Hz)	50±0.1%
	Waveform	Pure sine wave
	Waveform distortion rate(THD) (Linear load)	≤3%
	Dynamic response time (load 0←→100%)	5%
	Power factor(PF)	0.8/0.7/0.6
	Overload	120%,30seconds
	Inverter efficiency (80% resistive load)	≥85%
DC OUTPUT	Output voltage(Vdc)	48	44—57.6
	Output current(A)	20	0--20


Work environment	Dielectric strength (input and output)	1500Vac,1minutes
	Noise(1Meter)	≤50dB
	Ambient temperature	-5℃~+50℃
	Humidity	0~90%,No condensation
	Altitude(m)	≤1000
Indication	LCD indicate	Battery voltage,Output voltage,Output current etc
Indication	Inverter status	LED indication
Mechanical Dimension	(T×W×H)(mm)	280×420×610
Mechanical Dimension	Weight(Kg)	30
Protection function		Undervoltage, overvoltage, output overload, short-circuit protection
