Help CenterFrp Pultruded Fiberglass Rods Made in China 6mm , 8mm , 10mm , 12mm , 30mm
Related Products
-
High Strength Fiberglas Sold Rods 10mm, Solif Fiberglass RodsUS$ 0.2 - 0.8MOQ: 1000 Meters -
Chinese Manufacturer Flexible Fiberglass Rod, Solid Glass RodUS$ 0.1 - 1.5MOQ: 1000 Meters
-
High Strength and High Temperature Fiberglass Rods Poles ,solid Fiberglass RodsUS$ 0.1 - 2MOQ: 1000 Meters
-
Factory Price 3mm 6mm 10mm Fiberglass Rods, Colorful Solid Fiberglass RodsUS$ 0.2 - 0.6MOQ: 1000 Meters
-
High Strength and Good Corrosion Resistant Fiberglass Rod, Colour Fiberglass RodsUS$ 0.1 - 0.9MOQ: 1000 Meters
|
Fiberglass Solid Rod * E-class ( Fiberglass)+ Vinyl resin (Iso 9001-2008 Compliant)* *the below sheet is ou egular size ,custom size and custom shape can be accpted ,welcome for inquiry ,we ae factory that can promise low price good quality* | |
Diameter ( mm ) |
Diameter ( inch ) |
1.0 |
.039 |
1.5 |
.059 |
1.8 |
.071 |
2.0 |
.079 |
2.5 |
.098 |
2.8 |
.110 |
3.0 |
.118 |
3.5 |
.138 |
4.0 |
.157 |
4.5 |
.177 |
5.0 |
.197 |
5.5 |
.217 |
6.0 |
.236 |
6.9 |
.272 |
7.9 |
.311 |
8.0 |
.315 |
8.5 |
.335 |
9.5 |
.374 |
10.0 |
.394 |
11.0 |
.433 |
12.5 |
.492 |
12.7 |
.500 |
14.0 |
.551 |
15.0 |
.591 |
16.0 |
.630 |
18.0 |
.709 |
20.0 |
.787 |
25.4 |
1.000 |
28.0 |
1.102 |
30.0 |
1.181 |
32.0 |
1.260 |
35.0 |
1.378 |
37.0 |
1.457 |
44.0 |
1.732 |
51.0 |
2.008 |
.
Features:
| 1. Low Density: 67%~74% of aluminum | 6. Electrical Insulation |
| 2. High Strength, Tenacity, and Modulus | 7. Thermal Non-Conductivity |
| 3. High Corrosion Resistance | 8. Dimensional Stability |
| 4. UV Resistance | 9. Easy Fabrication and Installlation |
| 5. Electromagnetic Transparency | 10. Applicability under Wide Temperature Range |
Physical & Chemical Properties of Pultruded Profiles Vs. Other Structural Materials
| Mechanical Properties | Pultruded FRP | Rigid PVC | Mild Steel | Stainless Steel | Wood |
| Specific Gravity | 1.8 | 1.38 | 7.8 | 7.92 | 0.52 |
| Thermal Conductivity (Kcal/hr/m2/ C) |
24.4 | 6.4 | 1220 | 732 | 0.4 |
| Coeff. of Linear Expansion (cm/cm C) x 10-6 |
5.2 | 37 | 8 | 10 | 1.7 |
| Safe Working Temp. °C | 130 | 55 | 600 | 600 | 160 |
| Flame Resistance | Good* | Poor | Excellent | Excellent | Poor |
| Corrosion Resistance | |||||
| a. Acidic | Excellent | Good | Poor | Excellent | Poor |
| b. Alkaline | Good | Fair | Good | Excellent | Poor |
| c. Solvents | Fair | Poor | Good | Excellent | Fair |
| d. Coastal environment | Excellent | Good | Poor | Excellent | Fair |
| e. Outdoor Exposure | Excellent | Poor | Fair | Excellent | Fair |
| f. Effluent Water | Excellent | Good | Poor | Excellent | Fair |
| g. Steam | Good | Poor | Fair | Excellent | Fair |
Appication:
1) Outdoor activities: tent Pole, kite Rod, arrow shaft, ski pole, fishing rod, golf shaft, sail batten, hockey stick, kick board, skate boards, paddle shafts, bows and arrows, crossbows, golf shafts, slide guides, boat, kayak
2) Tool: umbrella shaft, umbrella rod, curtain rod, fence post, handrail, frame for cases and bags, oil sucker rods, bolts, stair, ladder, greenhouse structures, scaffold, portable work platforms, cooling tower, luggage rack, window/door frame, sign post, bus bar supports, tool handles, bike flags, flag poles, floor gratings, shoe soles, protective cases for laptops and iPhones
3) Toys: model cars/planes/helicopters, unmanned aerial vehicles, formula-1 race car
4) Vehicle: motor top sticks, u-shaped motor stator wedges, service truck booms, snowmobile track stiffeners, high-end automobile components, bicycle frames, glider, microcar, bodyshell, wind turbine blade
5) Pipe: gutters, gas / drinking water/ waste water pipe
6) Building: roofing laminate, flat roof, door surrounds, over-door canopies, window canopies and dormers, chimneys, insulators, cable conductor, cable tray, antenna, transformer air duct spacer sticks, cable support trays, switch actuators
frp, fiberglass, frp product, fiberglass product, frp tube, fiberglass tube, fiberglass pipe, glass fiber product, fiberglass rod, fiberglass pole, FRP pole
