JCL10F LED solar powered portable airfield light/runway light/taxiway light
Description
The solar powered JCL10F is a field proven aviation light that offers enormous benefits over traditional battery and hard-wired aviation lights including low maintenance and no underground wiring.
These completely self-contained LED lights are designed to suit a range of aviation and
general applications including emergency airstrip, caution, taxiway, and threshold lighting.
The unit has two high-performance solar modules mounted within the lens, which maximize
solar collection and provide reliable operation in a range of environmental conditions.
The focal plane of the light is designed to provide a vertical divergence of between 0 and
+7 degrees, and the user-replaceable battery ensures a service life of up to 12 years.
Features:
--Integrated solar/battery system
--Dual internal high-performance solar modules angled to maximize solar collection
--Fast&easy to deploy - no programming
---IP67 waterproof rating
--User-replaceable battery
--All hardware of obstruction lights are made of corrosion resistant metals.
--Ultra-high intensity LEDs
--Use of quality components and sophisticated technology reduce chances of maintenance and replacement.
--Low power consumption, which leads to huge savings on electricity bills.
--LED light source ensures long lifetime, maintenance free
--Shock and vibration resistant
--Corrosion resistant and UV stable polycarbonate housing
--Ease of mount, mount accessories available
Specifications:
Light Characteristics:
Light Source: 18 ultra-high intensity LEDs 18 ultra-high intensity LEDs
Available colors: Red, Green, White, Yellow, Amber, Blue, Sectored Combinations
Peak Intensity (cd): Steady-on: Blue - 2.8 Red - 6.8 Green - 9.0 White - 7.0 Yellow - 6.5
Flashing: Blue - 5.5 Red - 18.2 Green - 21 .9 White - 19.1 Yellow - 15.1
Horizontal Output (degrees): 360
Vertical Divergence (degrees): 0 to +7
Available Flash Characteristics: >250 including steady-on (user-adjustable)
Intensity Adjustments: Adjustable in 25% increments
LED Life Expectancy (hours): >100,000
Electrical Characteristics
Operating Voltage (V): 3.6
Temperature Range: -40 to 80°C
Solar Characteristics
Solar Module Type: Multicrystalline
Output (watts) : 4.8 (watt)
Solar Module Efficiency(%): 17
Charging Regulation: Microprocessor controlled
Power Supply
Battery Type: High grade NiMH
– Environmentally friendly
Battery Capacity (Ah) :8
Nominal Voltage (V) :3.6
Autonomy (nights): Steady-on: >14
Flashing: >38 (14 hour darkness,12.5% duty cycle)
Radio Controlled (optional)
Physical Characteristics
Body Material: Die Casting Aluninum
Lens Diameter (mm/inches) 140 / 5½ 140 / 5½
Product Life: Expectancy Up to 8 years
Environmental Factors:Humidity 0 to 100%
Wind Speed: Up to 160kph
Warranty: 2 years warranty
Options Available: • Radio Controlled – FCC compliant
• Lansin g Pilot Activated Lighting Control
• IR LEDs
• External ON/OFF Switch
• External Battery Charging Port
• Manual Operation
Applications:
--- Solar Barricade Light
---Solar Caution Light
--- Solar Taxiway Light(ICAO)
---Solar Threshold Light
---Solar Obstruction Light
