Home > Electrical & Electronics > Power Transmission & Transformer > Transformer > WP800 Series Vector Frequency Inverter With CE

WP800 Series Vector Frequency Inverter With CE

Name: WP800 Series Vector Frequency Inverter With CE
Brand: Winston
SKU: 110976095

WP800 Series Vector Frequency Inverter With CE thumbnail-1

WP800 Series Vector Frequency Inverter With CE photo-1

US$ 200 - 10,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Winston

Model Number:

WP800

Contact Supplier Request Quote Chat Now

Yueqing Winston Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Winston

Model Number WP800

Technique parameter

Features

1. Control Mode: SAPWM vector control.

2. 0.00~400.00Hz Output frequency range: 0.00~400Hz

3. Instruction Passage Mode: Operator Panel, Terminal Control, Long-distance communication control.

4. Frequency setting the signal: Number keyboard, Analog setting ( current, voltage signal ). Long-distance setting, Multi-Phase speed setting. Terminal assembled. PID closed-loop setting.

5. Big Jump-start torque: 0.5 Hz/150%

6. 1.0K~10.0kHz Carrier frequency range: 1.0K~10kHz

7. DC Current Braking: Start and Stop DC current braking can be adjusted solely.

8. Speed control precision: ± 0.5% the top speed (SVC) Automatism voltage modulate: ( AVR): Can keep output voltage invariableness automatically when the power net and voltage changes.

9. Automatism restrict current: Can restrict the Maximum current of the motor. And can protect the inverter and the motor reliably.

10. PLC program control: Single Cycle, continuous loop, wobble control and are fit for all kinds of field's demand.

11. Input, output terminal are programmable and are convenient for user.

12. Analog signals output, voltage and current can be selected.

13. Range: From 0.4KW to 400KW

14. For more details, please contact us, we will send all to you in time.

Data:

WP800-0R7G/1R5P	0.75/1.5	2.5A/3.7A	*170125162*
WP800-1R5G/2R2P	1.5/2.2	3.7A/5A	*170125162*
WP800-2R2G/004P	2.2/3.7	5A/9A	*220150175*
WP800-004G/5R5P	3.7/5.5	9A/13A	*220150175*
WP800-5R5G	5.5	13A	*300216212*
WP800-7R5P	7.5	17A	*300216212*
WP800-7R5G/11P	7.5/11	17A/25	*372274226*
WP800-011G/015P	11/15	25A/32A
WP800-015G/018P	15/18	32A/37A
WP800-018G	18	37A
WP800-022P	22	45A	*465302241*
WP800-022G/030P	22/30	45A/60A
WP800-030G/037P	30/37	60A/75A
WP800-037G/045P	37/45	75A/90A	*610360300*
WP800-045G/055P	45/55	90A/110A	*610360300*
WP800-055G/075P	55/75	110A/150A	*684424324*
WP800-075G/093P	75/93	150A/176A
WP800-093G/110P	93/110	176A/210A
WP800-110G/132P	110/132	210A/250A	*880504338*
WP800-132G/160P	132/160	250A/300A	*880504338*
WP800-160G/185P	160/185	300A/340A	*1410574430*
WP800-185G/200P	185/200	340A/380A	*1410574430*
WP800-200G/220P	200/220	380A/415A	*1600780470*
WP800-220G/250P	220/250	415A/470A
WP800-250G/280P	250/280	470A/520A
WP800-280G/315P	280/315	520A/600A	*1700850498*
WP800-315G/350P	315/355	600A/640A
WP800-355G/400P	355/400	640A/690A
WP800-400G/450P	400G/450	690A/780A	*1700850523*
WP800-450G/500P	450G/500	780A /860A	*22201200550*
WP800-500G/560P	500G/560	860A/950	*22201200550*
WP800-560G/630P	560G/630	950A/1100A	*22201200550*
WP800-630G	630	1100A	*22201200550*

Packaging & Shipping

What is the packing for our product?

What is the delivery way?

(1)If ship by sea and Air,you can get Bill of Loading,CO,Commerical invoice,Packing list from us after ship.

(2)If ship by express company,you will get a Tracking No. from us after ship.

Our Services

What the Certifications do we have obtained?

What is the payment?

What's the Refund & Replacement?

1. 90-day-warranty.

If there is any quality problem (defective / don't work) of the goods, it could be returned within the warranty days. (Please notify us as soon as possible)

2. Any items must be returned in their original condition to qualify for a refund or replacement. (Any used items cannot be refunded or replaced).

Company view

Our team

FAQ

How to choose our inverter?

1. Single output

To determine the power after the output voltage is decided. The power range of our switching power supply is 10W to 1500W, output voltage from 3V to 220V DC. If the requirement is 24V, 1A, we can choose S-25-24, and within cost range, retain 10% -20% of the power allowance.

2. Multi-output

The multi-output power supply has the main and secondary circuit output. The character of main circuit output is better than the secondary.To ensure the load regulation and so on, every circuit has to be with a certain load. If just using the second circuit, the main circuit has to be matched with corresponding dummy load (more than 0.5A or larger)

3. Before placing an order, please kindly confirm us the details below: Input voltage, Output voltage, Output current, Power,waterproof or not, special size or not, and other special requests.

4. When purchasing the power supply, the customer should know the operation environment, for example, temperature, humidity, altitude, etc.

How to installation our inverter?

Please use the proper screw to fix the power supply in the applicable environment, the screw length should be less than 6mm, cannot reach to the circuit boards, to avoid touching the internal components and conductive dangerous.

There should be ventilation channels or exhaust devices in the power supply working space. In order to ensure the use security and avoid reduce the interference; please make sure that earth the ground wire well. The ground wire is large than AWG#.

After installation, please measure the insulation resistance of shell between input and output, to avoid electric shock.

Questions for our inverter?

1. When using your inverter, find the shell with voltage, is that normal?

Answer: That is normal. According to the EMI request, the input port and the shell are connected by a capacitor, which causes the voltage on the shell. It’s specified in the IEC standard that the leakage current is less than 3.5mA. It’s safe and won't cause any damage to people.

2. When needing 24V voltage, but only 12V power supply at hand, can this work to connect 2 pieces 12W power supply in series?

Answer: It’s workable. We can cut down the cost through that way sometimes.

3. Can use S-50W power supply as the charging power supply?

Answer: Yes. But in order to avoid battery feedback, please be advised use a series diode on the output, and pay attention to the diode heat dissipation.

4. Why the power supply fails to boot correctly?

Answer: When the load is electric, light bulbs or capacitive load, the instantaneous electric current is excessive when booting, it can cause overload protection. In this case, please choose the appropriate power or contact the manufacture factory.

What is the MOQ of our inverter?

MOQ: We support sample order.(1~5PCS)

More than 500PCS,can pring Logo on the products.

How to Visit and contact us?

Firstly, you are highly welcomed to visit our factory, we can provide you an invitation letter from Chinese Embassy for you if needed.

Besides, we are more pleased to help you to book a flight or hotel to save your time.
