Navigation Aids-Ultra PE Navigation Buoy :
Ultra PE Navigation Buoy Characteristics:
Material: ULTRA-HIGH MOLECULAR WEIGHT ≥25,000,000, with Closed Cell Polyurethane Foam filled, galvanized steel structure inside.
1.Maintenance Free:
no need to paint, no need to maintain and repair, no need to shovel the water growth, saving manpower and resources.
2.Higher Impact Resistance:
a. The material has higher flexibility and hardness, when impacted, it will not deform.
b. There is steel skeleton inside the floating body, with the pouring density of Polyurethane foam ≥46kg/m³ and it plays a powerful support to the floating body.
3. Long Life
a. With high chemical stability and high anti corrosion, the buoy will not
decompose for decades in the seawater, meanwhile, it will not pollute the water.
b. The floating body and tail pipe are very resistant to outdoor ultraviolet radiation. It will not be aging for decades and the mechanical properties will not change.
ULTRA PE NAVIGATION BUOY SPECIFICATION:
| Size | Diameter(mm) | Buoying Depth(m) | Freeboard(mm) | Focal Plane Height(mm) | Net Weight(kg) | Height(mm) | Reserve Buoyance(kg) |
| CMB800 | 800 | 1.5-10 | 450 | 1580 | 195 | 2900 | 230 |
| CMB1200 | 1200 | 2-20 | 510 | 2040 | 550 | 3380 | 570 |
| CMB1500 | 1500 | 4-20 | 632 | 2524 | 681 | 4100 | 1012 |
| CMB1800 | 1800 | 6-30 | 722 | 3031 | 1686 | 5034 | 1546 |
| CMB2100 | 2100 | 8-40 | 800 | 3518 | 1900 | 5757 | 2450 |
| CMB2400 | 2400 | 10-50 | 975 | 4527 | 2973 | 6930 | 4015 |
| CMB3050 | 3050 | 15-60 | 1114 | 5164 | 3490 | 7610 | 7646 |
| CMB3500 | 3500 | 20-70 | 1240 | 6090 | 3863 | 8520 | 11380 |
Structure of Ultra PE Navigation Buoy:
Certificate:
Plastic(Ultra PE) Marine Navigation Mark Buoy in Deployment Showed in the Photos as Below:
