Wire Cutting Crimping Machine

Wire Cutting Crimping Machine photo-1
US$ 27,000 - 29,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
YaTai
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Guangdong, China
Brand Name YaTai
Model Number YT-7802
Voltage 220v
Power(W) 1000W
Dimension(L*W*H) 1070x1020x1450mm
Weight 450kg
Certification ISO9001,CE
Warranty 1 year
After-sales Service Provided Overseas service center available

Specifications

1.Full servo motor drive
2.Japan THK slider
3.Japan SMC pneumatic parts
4.Two ends crimping


Product Description

<

Model No. YT-7802
Gauge AWG1007#14-#28
Drive mode 4000pcs/h(L≤100mm)
Capacity Mitsubishi Servo with four drives
Function Cut,strip,crimp with both ends
Cutting length 40mm-9999mm
Cutting tolerance ±0.2mm+(L*0.002mm)
Stripping length 0-15mm(both ends)
Mould of crimping NO.1OPT;NO.2Horizontal&perpendicular
Crimping machine 2T crimping machine with low noise
Control Professional Central Process Unit
Test ability no wire;tie a knot;crimp with fault way;low pressure
Voltage AC220V-50/60Hz single phase
Air pressure 0.5Mpa(140NL/min)
Measurement 1070*1020*1450 L*W*H mm
Weight 450kg
Selected unit Wire feed,Wire collect,CFM







Machine Details

wire cutting crimping machine

wire cutting crimping machine

wire cutting crimping machine

wire cutting crimping machine





Processing Workshop





Assembling Workshop

wire cutting crimping machine





Package and Shipping

wire cutting crimping machine



Certificates





  wire cutting crimping machinewire cutting crimping machinewire cutting crimping machine

1. Full automatic crimp machine YT-7802,we have stock,we can delivery it at any working time after you payment,

2. Use film to cover it,then package it by wooden case

3. According to the destination,we will compare several transportation companies and select the most suitable and economic one to provide service for us

4.  Check the machine's quality and test it before shipping

5.  Provide free guidance before you start using our terminal crimping machine

6.  1 year warranty

7.  Free remote guidance by video chat when you have problem during use the terminal crimping machine
