Help Center12v FC280SC dc Motor for Door Lock
Negotiable
MOQ: 1000 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chaoli
Model Number:
CL-FC280SC-18180
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chaoli CL-0816 Coreless dc MotorNegotiableMOQ: 1000 Units -
3.5v CL-WS1215N Medical ApplianceNegotiableMOQ: 1000 Units
-
CL-FFM20 DC Motor for Controller RelayNegotiableMOQ: 1000 Units
-
CL-RS540SH DC Motor for DC Fan MotorNegotiableMOQ: 1000 Units
-
CL-FFN10WA DC Motor for Tilt CameraNegotiableMOQ: 1000 Units
Place of Origin
Guangdong, China
Brand Name
Chaoli
Model Number
CL-FC280SC-18180
Usage
Boat, Car, Electric Bicycle, Fan, Home Appliance
Certification
ROHS
Type
Micro Motor
Torque
40.3g.cm
Construction
Permanent Magnet
Commutation
Brush
Protect Feature
Drip-proof
Speed(RPM)
9600 rmp/min
Continuous Current(A)
0.07A
Output Power
0.1W~5.6W
Voltage(V)
12
Efficiency
IE 2
Specifications
Key Specification1.Diameter:2 mm
2.Length: 45mm
3.Voltage range:1.5~3.0V
dc motor
12v FC280SC dc motor
| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | ||||||||
| operating range | nominal | speed | current | speed | current | torque | output | torque | current | |||
| r/min | A | r/min | A | mN.m | g.cm | W | mN.m | g.cm | A | |||
| CL-FC280PC-22125 | 8.0-16 | 12 | 12500 | 0.09 | 11090 | 0.71 | 4.76 | 48.6 | 5.52 | 42.2 | 430 | 5.56 |
| CL-FC280SC-18180 | 8.0-16 | 12 | 9600 | 0.07 | 8270 | 0.43 | 3.95 | 40.3 | 3.42 | 28.5 | 291 | 2.7 |
| CL-FC280SC-20150 | 8.0-16 | 12 | 11800 | 0.081 | 10310 | 0.56 | 4.14 | 42.2 | 4.47 | 32.9 | 335 | 3.9 |
| CL-FC280SC-16220 | 8.0-16 | 12 | 7900 | 0.055 | 6780 | 0.33 | 3.27 | 33.3 | 2.3 | 23 | 234 | 2.0 |
FC280SC dc motor FC280SC 12v dc motor electrical motor
dc motor 12v dc pump motor 12v dc water motor
