Specifications
V-type air cooled condenser-Aluminum fin&copper tube condenser
-fin space2-3mm
-Surface:60-505m2
-Top Quality
Top Quality High Efficiency FNV Type Air Cooled Condenser for Food&Vegerable Fresh,Quick Freezing and Cold Storage Room
Introduction
Air cooled condenser is a kind of cooling devices by utilizing air which connected with Freon refrigeration equipments. Now we produce FN, FNS type and FNV type air cooled condenser, Air side outlet for FN&FNS type and Air top outlet for FNV type.
Features
1. The outcovering is made of high-quality steel plate with sprayed surface to ensure corrosion resistance, beautiful appearance;
2. Coil adopted staggered permutation,and tighted to fit with Aluminum sheet to ensure high efficiency heat exchange;
3. Units adopted 2.8MPa air tightness test and system sewage discharge treatment;
4. Application for R22,R134a,R404a,R407C etc. refrigerant;
5. FNS condenser utilized large air volume and low speed internal motors with low noise,beautiful appearance; Application for refrigerant equipments which denmand high requirements of noise;
6. FNV condenser have the features of large windward side, high quality heat exchange; external rotor motors used.
Models Specifications
FN S ----- 80 A
FN: Condenser Products Code
S: Type: S(Low Noise Type); V(Air Top Outlet Type); P(Water Spray Type); None(Standard Type)
80:Heat Exchange Area(2)
A: Model Change Design Code
FNV Type:Air Top Outlet Models:FNV--70 TO FNV--505A
Overall Size
FNV Type Models Technical Data Sheet:
| Models No. | Nominal heat exchange | Area | Fan | Diameter of Interface | ||||
| KW | m2 | Power(W) | Diameter(mm) | Voltage(V) | Air Flow(m³/h) | Inlets | Outlets | |
| FNV-70A | 22.4 | 70 | 2×450 | 500 | 380 | 13000 | 2×φ22 | 2×φ16 |
| FNV-105A | 33.7 | 105 | 2×600 | 550 | 380 | 17400 | 2×φ22 | 2×φ16 |
| FNV-140A | 44.9 | 140 | 2×600 | 550 | 380 | 17400 | 2×φ22 | 2×φ16 |
| FNV-175A | 55.4 | 175 | 2×800 | 630 | 380 | 26000 | 2×φ28 | 2×φ22 |
| FNV-195A | 62.1 | 195 | 2×800 | 630 | 380 | 26000 | 2×φ28 | 2×φ22 |
| FNV-260A | 83.2 | 260 | 3×800 | 630 | 380 | 39000 | 2×φ28 | 2×φ22 |
| FNV-295A | 93.4 | 295 | 3×800 | 630 | 380 | 39000 | 2×φ28 | 2×φ22 |
| FNV-365A | 116.5 | 365 | 3×800 | 630 | 380 | 39000 | 2×φ28 | 2×φ22 |
| FNV-405A | 130 | 405 | 4×800 | 630 | 380 | 52000 | 2×φ35 | 2×φ28 |
| FNV-505A | 162 | 505 | 4×800 | 630 | 380 | 52000 | 2×φ35 | 2×φ28 |
FNV Type Models Overall Size and Installation Size:
| Models No. | Overall Size:mm | Installation Size:mm | ||
| A×B×C | a | b | ||
| FNV-70A | 1455×976×952 | 1330 | 896 | |
| FNV-105A | 1455×976×952 | 1330 | 896 | |
| FNV-140A | 1455×976×952 | 1330 | 896 | |
| FNV-175A | 1755×1050×1050 | 1630 | 970 | |
| FNV-195A | 1755×1050×1050 | 1630 | 970 | |
| FNV-260A | 2555×1050×1050 | 2430 | 970 | |
| FNV-295A | 2555×1050×1050 | 2430 | 970 | |
| FNV-365A | 2555×1050×1050 | 2430 | 970 | |
| FNV-405A | 3155×1112×1144 | 3030 | 1032 | |
| FNV-505A | 3155×1112×1144 | 3030 | 1032 | |
Products in Factory
