Specifications
Air Cooled Condenser-Top Quality
-V Type
-For Refrigeration
-For Condensing Unit
Top Quality High Efficiency FNV Type Air Cooled Condenser for Refrigeration,Condensing Units with Large Windward Side,High Quality Heat Exchange,External Rotor Motors
Introduction
Air cooled condenser is a kind of cooling devices by utilizing air which connected with Freon refrigeration equipments. Now we produce FN, FNS type and FNV type air cooled condenser, Air side outlet for FN&FNS type and Air top outlet for FNV type.
Features
1. The outcovering is made of high-quality steel plate with sprayed surface to ensure corrosion resistance, beautiful appearance;
2. Coil adopted staggered permutation,and tighted to fit with Aluminum sheet to ensure high efficiency heat exchange;
3. Units adopted 2.8MPa air tightness test and system sewage discharge treatment;
4. Application for R22,R134a,R404a,R407C etc. refrigerant;
5. FNS condenser utilized large air volume and low speed internal motors with low noise,beautiful appearance; Application for refrigerant equipments which denmand high requirements of noise;
6. FNV condenser have the features of large windward side, high quality heat exchange; external rotor motors used.
Models Specifications
FN S ----- 80 A
FN: Condenser Products Code
S: Type: S(Low Noise Type);
V(Air Top Outlet Type); P(Water Spray Type); None(Standard Type)
80:Heat Exchange Area(m2)
A: Model Change Design Code
Technical Specification
| FNV Type Models Technical Data Sheet: | ||||||||
| Models No. | Heat Exchange Capacity | Area | Fan | Diameter of Interface | ||||
| KW | m2 | Power(W) | Diameter(mm) | Voltage(V) | Air Flow(m³/h) | Inlets | Outlets | |
| FNV-70A | 22.4 | 70 | 2×450 | 500 | 380 | 13000 | 2×φ22 | 2×φ16 |
| FNV-105A | 33.7 | 105 | 2×600 | 550 | 380 | 17400 | 2×φ22 | 2×φ16 |
| FNV-140A | 44.9 | 140 | 2×600 | 550 | 380 | 17400 | 2×φ22 | 2×φ16 |
| FNV-175A | 55.4 | 175 | 2×800 | 630 | 380 | 26000 | 2×φ28 | 2×φ22 |
| FNV-195A | 62.1 | 195 | 2×800 | 630 | 380 | 26000 | 2×φ28 | 2×φ22 |
| FNV-260A | 83.2 | 260 | 3×800 | 630 | 380 | 39000 | 2×φ28 | 2×φ22 |
| FNV-295A | 93.4 | 295 | 3×800 | 630 | 380 | 39000 | 2×φ28 | 2×φ22 |
| FNV-365A | 116.5 | 365 | 3×800 | 630 | 380 | 39000 | 2×φ28 | 2×φ22 |
| FNV-405A | 130 | 405 | 4×800 | 630 | 380 | 52000 | 2×φ35 | 2×φ28 |
| FNV-505A | 162 | 505 | 4×800 | 630 | 380 | 52000 | 2×φ35 | 2×φ28 |
Pictures of Products
