Quick Details
- Place of Origin: Shaanxi, China (Mainland)
- Brand Name: ELITE
- Application: Industrial Instruments and Equipments
- Supply Voltage: 3-6VDC
- Material: alunimium anodized or brass
- Color: Brass or silver or black
- Beam type: dot, line, cross
- Certificated: FDA IEC SGS ISO9001-2008
Packaging & Delivery
| Packaging Details: | One Unit packed with condense foam, Bulk into export cartons. |
|---|---|
| Delivery Detail: | 10-20day depending on the QTY |
Specifications
Ten years experience with manufacture and design FDA IEC SGS ISO9001-2008 Low Consumption High Reliability LongLife Span
Key Features
1, High quality industrial laser diode
2, Small dimension
3, Low cost
4, Low consumption
5, Long Life
Application:
1. Gun laser sight
2.Laser alignment
3.Bar scan
Specifications
Items |
Specifications |
||||||||
Spectral Range |
Violet |
Blue |
Red |
Infrared |
|||||
Wavelength |
405nm |
450nm |
635nm |
650nm |
780nm |
808nm |
830nm |
850nm |
980nm |
LD power(mW) |
5- 50 |
5-60 |
5~180 |
5~150 |
5~200 |
50~5000 |
5-100 |
5~100 |
20~5000 |
Operating Current |
25~5000mA |
||||||||
Input Voltage |
2.6~5.5VDC |
||||||||
Operating Temp. |
-10°C ~ 50°C |
||||||||
Storage Temp. |
-40°C ~ 80°C |
||||||||
Power Stability |
> 98% (@2.7 ~ 5.5VDC) |
||||||||
> 95% (@-10°C ~ 50°C) | |||||||||
MTTF |
>10000 Hrs. |
||||||||
Circuit Protection |
Static, Surge, and Reverse Polarity Protected |
||||||||
Case Material |
Brass or Aluminum |
||||||||
Beam Pattern |
Dot, Line ,Cross |
||||||||
We could customize for you.
What we produce?
Mini laser diode module,small dimension and with low comsumption,is particularly suitable for builtin minature devices and tools,which could enable the laser tools and equipements miniaturized.Mini laser diode module is mainlky applied in gun laser sighting,bar code scanning etc.
