Home > Manufacturing & Processing Machinery > Commodity Making Machine > Straw Making Machine > Five Colours Extrusion

Five Colours Extrusion

Name: Five Colours Extrusion
Brand: Marrow
SKU: 111460081

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

Marrow

Model Number:

ML15

Contact Supplier Request Quote Chat Now

Nanjing Marrow Machinery Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI/NANJING

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name Marrow

Model Number ML15

Voltage 380V

Power(W) 1.5kw

Dimension(L*W*H) 8m*1.5m*1.6 m

Weight 2800kg

Certification CE/ISO9001

Warranty One Year

ML15 FIVE COLOURS STRAW EXTRUSION LINE

DESCRIPTION

Model ML11/ML12/ML13/ML14/ML15 is a tube extrusion line, composed of extruder and die, size setting and water cooling unit, haul-off unit, rotary cutter unit, The series machines can produce all kinds of drinking strawspiral strip strawfrom one color to five color , medical pipe, all the machines controls base with the control elements ergonomically adapted to permit easy operation..

TECHNICAL FEATURE

1. The extrusion die can be special designed and easy exchanged to produce pipe and shaping stuff,

2. Water bath in stainless steel can be adjusted in three planes ,

3. The haul-off unit can be belt or rollers, it is customizable.

4. Fitted with single or double rotary cutter.

5. Conveyor device(you may select if you want)

SPECIFICATIONS

Model		ML11	ML12	ML13	ML14	ML15
Parameter of main screw		φ50mm(diameter)
Parameter of sub- screw		0	1×φ25mm	2×φ25mm	3×φ25mm	4×φ25mm
Capability		25~35Kg/h
Power supply	Main motor	11kW 380v 50Hz (VFD)
	Sub motor	0	0.75kW×1		0.75kW×3	0.75kW×4
	Haul-off motor	0.75kW×1(VFD)
	Cutting motor	0.75kW×1(VFD)
ntroller		5zone	8 zone	11 zone	14zone	17zone
Heating power		8.1kw	11.63kw	14.75kw	18kw	20.8kw
Length of cooling container		3400mm/6400mm
Specifications		diameterφ3~12mm thickness0.08~1mm
Machine weight		1400KG	1700KG	2000KG	2400KG	2800KG
Dimension		1500mm(W)×9000mm(L)
Other specifications are customizable
