ML28 TELESCOPE STRAIGHT STRAW MAKING MACHINE
DESCRIPTION
Model ML28 Telescope straight straw auto making machine is a special machine of making telescope drinking straws. They are consist of 3 sets of machines,One is expanding for inner straw, others two sets machine is shrinking for outside straw. The straight straws supplied in the hopper at the top of machine ,passes through 12 sets of conveyor and 12 sets of heating die, delivered to output conveyor automatically.
TECHNICAL FEATURE
1. High efficiency and high production rate,
2. Automatic product counting,
3. Expanding and shrinking of telescope straw can be adjusted,
4. Hopper in stainless steel is set at conveyor, one man can operate two machines,
SPECIFICATIONS
Model |
ML28-4.5 |
ML28-5.5 |
ML28-5.5 |
|
Function |
Inner expanding |
Outside shrinking |
Outside shrinking |
|
Capability |
200250pcs/min |
|||
Main motor |
0.75kW (VFD) |
|||
Power of heater die |
1.5kW |
|||
Specifications of straw |
Diameter of straw |
Φ4.5mm |
Φ5.5mm |
Φ5.5mm |
Length of straight straw |
90130 |
80120 |
80120 |
|
Thickness of straw |
0.190.25 mm |
|||
