Specifications
Crystaljet 4000 Series1. Use SPT510/35pl
2. high resolution with 1440dpi
3. Good quality, low price
3000 Series solvent printer &inkjet printer Spt 510/35 Spt 510/50
1.Use SPT510/35pl
2.high resolution with 1440dpi
Crystaljet 3000 Features:
- Strong bridge frame body provides a stable body.
- Capping device and cleaning gate provides an open space for maintenance.
- Full range of complementary molding parts, achieves high precision assembly.
- Improved 3 zones heating system with front, middle and rear 3 parts, avoiding medias or printing
platform expansion and contraction. - Cleaning LED light with glass cover ,easy for printhead cleaning ,Light has automatically shut off function ,it extend the using life of LED.
- Both sides have adjustable stands, which ensures the printer work on a horizontal level and avoiding medias going skewed.
- This printer provides positive flush and solvent flush ,suction function, with each color ink prime.
- The safety of low voltage and print head heating system allows the printer can be worked on varies environment.
- Pre heating on rear heating board, middle heating board with higher temperature improves ink absorption, precision printing and working efficiency.
- Auto white skip, auto step adjustment, bi-direction value, single map automatically copy, wave technology,eclosion, friendly operation interface makes printing process simple and easy.
- There is an option to select alert ink sub tank for convenient and safe ink refill.
- Optional constant temperature front hot dry fan system allows printer working under a low temperature and wet environment.
- Optional secondary ink tank constant temperature system, makes printer working good under a cold environment.
- Optional simple and easy operating take up system.
Model |
Cj4000 SPT510_35PL |
Cj4000 SPT510_35PL |
||
Print head |
SPT510_35PL |
|||
No of Print heads |
6PCS |
8PCS |
||
Print head Sequence |
1×6 |
2×4 |
||
Print Width |
3200mm 125.98inch |
|||
Media Width |
3220mm 126.77inch |
|||
Print speed |
Print mode |
speed |
||
High speed |
240X540 3pass 56m²/hr |
240X540 3pass 112m²/hr |
||
Middle speed |
240X720 4pass 41m²/hr |
240X720 4pass 82m²/hr |
||
Standard speed |
360X540 3pass 37m²/hr |
360X540 3pass 74m²/hr |
||
Ink Type |
Ink Type |
Solvent Ink |
||
Color |
KCMYLCLM |
KCMY |
||
Ink supply system |
Auto continuation ink supply, ink detective, failure notes ,main ink alarm(optional) |
|||
Cleaning method |
Single color positive flush(with pressure protection),auto flushing & head moisturize |
|||
RIP software |
Maintop( Photo Print, Ultra Print optional) |
|||
Interface |
USB2.0 |
|||
|
Printing assistant system |
Auto feeding system |
Infrared-detecting, feed & take-up system with memory function |
||
Heating system |
Three stage heating system(Preheating, Print- heating, post- heating) |
|||
Head heating |
Low-voltage consistant-temperature head-heating(DC24V) |
|||
Height of the tray |
2~5mm Distance to the printing platform, adjustable |
|||
Other functions |
One key positive-pressure ink injecting ,adjustable force of media being absopted to platform, anti-warp media-press ,subtank heater(optional),lighting for head cleaning, drying fan, anti-splash board, emergency stop, full waste tank prompt |
|||
Printer info |
Voltage |
AC220V 50/60HZ (AC110V 50/60HZ is optional) |
||
Power |
Printing system :500W Heating system(Post-,1000w, print-,1500w, pre-, 1000w) |
|||
Working environment |
Normal temperature:22~28°C Himidity:40%~70%RH |
|||
Machine size and weight |
4840mm(L)X1000mm(W)X1340mm(H) 520kg±15kg |
|||
Shipping size and weight |
4840mm(L)X1000mm(W)X1340mm(H) 520kg±15kg |
|||
