Intermediate Wire Drawing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-300-17DT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Threading and Pointing MachineUS$ 1 - 2MOQ: 1 Set -
Intermediate Copper Drawing Machine Copper Wire Cable Making Equipment Wire Cable MachineNegotiableMOQ: 1 Set
-
Intermediate Wire Drawing Machine With Annealing Copper Wire Drawing MachineNegotiableMOQ: 1 Set
-
( Wire Drawing Machine With Annealing ) Cable Tray Making MachineNegotiableMOQ: 1 Set
-
( Used Wire Drawing Machine / Wire Drawing Machine Price )copper Wire Making MachineNegotiableMOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
HONTA
Model Number
HT-300-17DT
Usage
Drawing
Specifications
Intermediate wire drawing machine:Adopt precisely ground gears for all transmission system.
Part one Component of HT-300-17DT Intermediate wire drawing machine:
1.HT-250F Pay-off
2.HT-300-17D Wire drawing machine
3.HT-2500A Annealer
4.HT-630A spooler
5.HT-200 Threading and pointing machine
6. Steam generator
7. Heat exchanger 6m2
8. Operation console
9. Electric control system
Part two Technical data:
Inlet wire diameter: max 3.50mm
Outlet wire diameter: φ0.80~φ2.50mm
Machinery speed: Max. 1500m/min
Nos. of dies: max. 17
External diameter of dies: 30mm
Area reduction: The final die is 8%, others are 15%
Diameter of drawing capstan: max φ300mm
Diameter of finished capstan: φ300mm
Power of main motor: AC55kw
