Test Stand

Test Stand thumbnail-1
Test Stand photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Hydraulic Power Units
Model Number:
ts-103
Brand Name:
american lab & systems
Contact Supplier Request Quote Chat Now
AMERICAN LAB & SYSTEMS
Payment & Shipping
Payment Methods:
Port of Shipment:
los angeles
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Hydraulic Power Units
Model Number ts-103
Brand Name american lab & systems
Place of Origin California, United States

Specifications

1=50 gpm styles available
0-10,000 psi

Type: Stationary Test Stand

This unit is capable of testing actuators, valves, accumulators, and hoses.

The Power Unit has a 700 series Denison variable volume pressure compensated pump.

It also includes a high pressure filter (3 micron), low pressure filter (10 micron), water heat exchanger, relief valve, check valve, drain valve, 80 gallon reservoir, electrical control enclosure with starter, fuses, and relay.

This Test Stand gauge panel and control valve panel are mounted on an angle iron frame with stainless steel work sink which drains into the reservoir.

The Test Stand construction is unique in that all hydraulic components are tank mounted behind the control panel, making access very easy to all items.

The black anodized aluminum gauge test panel includes:



  • (3) 6" dia pressure gauges, 6000 PSI
  • (1) 20 GPM flowmeter
  • (4) bulk head fitting and test ports
  • (4) Gauge shut off valve
  • (1) 3½" dia temperature gauge

    The black anodized aluminum control valve panel
    includes:



  • (1) push button stop/start station
  • (1) shut off valve
  • (1) 4 way, manual operated selector valve
  • (1) 0-10,000 PSI static circuit

    This is a self-contained test stand with new, overhauled, and factory warranted components.
