KB-125E/800 terrazzo tile press machine manufacturer in China
Introduce of KB-125E/800 terrazzo tile press machine manufacturer in China
(1) it can make biggest size 800*800mm terrazzo tiles
(1) by replacing the mold, KB-125E/800 also can make produce , 600 × 600mm, 500 × 500mm terrazzo tile, product thickness and weight can be adjusted by adjusting the quantitative Cup.
(2) high degree of automation, simple operation, equipment operation only 2-3 people.
(3) low production cost, labor intensity, low energy consumption and pollution.
(4) Product Dimension accurate, pressure, and high strength. Patterns varied, clear lines.
After-sales service: free assembly debugging product, is responsible for equipment operation training, free warranty for one year
Features of KB-125E/800 terrazzo tile press machine manufacturer in China
Various colors and suitable for decoration;
High strength, lightweight, low consumption, large single-piece area and high coverage.
Good insulation.
Anti-acid and rain, weathering-resistant, good weather ability and over-80 years service life expectancy.
Waterproofing and anti-permeation
Various kinds
Widely used. Products can be used in various buildings, practical and decorative.
KB-125E/800 terrazzo tile press machine manufacturer in China
also call it high effiency concrete floor tile machine, automatic molding machine, large capability forming machine, roof tile machine, roof tile conctere roof tile machine.
1. high speed, fast moding
2. high qulaity with Germany technolgy
3. steady performace
4. high daily capability
4. easy operation, saved operators
5. low investment
| 1 | Moulding machine | 1 set |
| 2 | constant feeder machine | 1 set |
| 3 | blender | 1 set |
| 4 | elevator machine | 1 set |
| 5 | air compressor | 1 set |
| 6 | polishing machine | 1 set |
| 7 | stacker machine | 1 set |
1).New type of cylindrical tile molding machine whit high forming speed, large output, and reliable performance. Using PLC (Mitsubishi technology) automatic control, hydraulic pneumatic, the speed of production can up to 6-9 pieces/ min, in a high yield, cost-effective priorities.
2). A new type of cylindrical molding machine, the underside of slid platform is made of semi-circular guide rail,rail, compared with the square guide rail more stable and more wear-resistant. Main oil cylinder and four-cylinder overall orientation, not only to improve the stability of the equipment, but also to extend the life of the mold.
3).Through the filter press type molding, product with beautiful structure, variety kinds, high density, strong strength, accurate size to meet the needs of various types of buildings are concrete products of quality products.
4). A multi-purpose machine, by replacing the mold, can produce various types main tile and matching tile.
the mainly performance of KB-125E/800 KB-125E/800 terrazzo tile press machine manufacturer in China
| KB-125E/800 terrazzo tile press machine manufacturer in China | |
| moulding presure | 300T |
| moulding speed | 3-4pcs/min, 2000pcs/shift |
| main frame power | 7.5 KW |
| main frame weight | about 16T |
| external dimension | 4100*2100*2880mm |
1)Its with the merits of fast molding speed, large output, reliable performance, PLC automatic control and convenient operation. Its hydropneumatic, with the speed as high as 5-6 pieces/min. 2000-3000pcs/shift=8hours/day.In addition, the rate of finished products is high, and the quality-price-relative is better.
2)The terrazzo tiles made of the mortar concrete with press-filtering molding are with the perfect structure. In addition, there are many kinds available, with high density, strong intensity, and nice dimensions, which are the excellent on the concrete products, meeting the different construction requirements
3)The machine is with multi - functional. By changing molds, it could be used to produce terrazzo floor tiles, ceramic tiles, curbstone blocks, marble tile... etc. In addition, it could also be used to product various top-grade colorful ground tile, including terrazzo tile, bathing tile, etc.
4)Our KB-125E/800 also can produce different roof tiles, such as margin tiles, ridge tile,main tile, roman tile, spanish tile...by changing molds. Very profitable for customers.
full production line for KB-125E/800 terrazzo tile press machine manufacturer in China
Roof tile Work flow: Elevating--- Mixing --- Fixed-quantity filling --- Pressure forming --- Mould unloading --- Forming tiles --- Onto the tiles shelf ---Maintenance (24 hours) --- Stacking --- Natural maintenance --- Ink jetting --- Finished products.
Floor tile work flow: Elevating - Mixing - Fixed-quantity filling -Pressure forming -Mould unloading - Forming tiles - Maintenance - Finished products
different types of terrazzo tiles which KB-125E/800 terrazzo tile press machine manufacturer in China can make both monolayer and double layer tiles
if change modules for KB-125E/800 terrazzo tile press machine manufacturer in China , also can make multifunctional products:
packging & shipping
one 20ft or 40ft can hold whole line as customer's requirment.
Our Services
Before-sale services:
(1) Tell customer how to build a brick plant, the complete plant including three parts, brick shaping machinery, drying and firing.(Confirm clay,power electricity,water,land area, fund)
(2) Guide customers to choose the best and economic plant, recover the investment within short time.
(3) site inspection
(4) We are responsible for the offer, flow chart, and detail specification of each machinery.
In-Sale services:
(1)Quality control must be inspected strictly
(2)In accordance with the agreements stipulated in the contract
After-sale services:
(1) We will send the technicians to guide with device installation, debugging and training operators until customers are fully satisfied.
(2) Guarantee for machinery, materials and equipment supplied under this quotation are valid for a period of 12 months after commissioning or 16 months after delivery whichever is earlier. Warranty shall cover manufacturing defect in material and workmanship but exclude:
a. Daily wear and tear 2.mishandling or improper operation3. Incoming power supply fluctuation
b. Consumable and spare parts.
(3) Regular visit customer, consult with the customer feedback, come true with the customer's two-way communication.
comoany information
we locates in jiangsu province, welcome you come to visit our factory, giving good suggestion and idea
FAQ
-- our floor tile production line has three models: 400, 500 and 600. Pls kindly inform us which model you like, we will quote you a good price.
-- we have shipping forwarder who cooperated with us for many years. if possible, we can use our forwarder to send equipment to you safely and tightly.
-- we need 30 days around to make machines. if stock have, time will be less.
-- we will send engineers to customer side for installation and training when equipment arrives at customers side.
-- we also usually help customer to buy accessories. we would like to introduce good supplier for customer to purchase other products.
for details information, pls feel free to contact with me of following. pls click left side weichat logo, you will be our partner. If you have time, we welcome your coming to visit our factory:
