Help CenterKBJX Single Layer Stripe Paver Blocks Production Line
Related Products
-
KBJX Concrete Stripe Stone MachineUS$ 7,500 - 40,000MOQ: 1 Set -
KBJX Low Investment Stripe Stone MachineUS$ 7,500 - 40,000MOQ: 1 Set
-
KBJX Whole Production Line for Stripe StoneUS$ 7,500 - 40,000MOQ: 1 Set
-
KBJX Small Plant Stripe Tile Making MachineUS$ 7,500 - 40,000MOQ: 1 Set
-
KBJX Concrete Stripe Paver Production LineUS$ 7,500 - 40,000MOQ: 1 Set
Specifications
KBJX single layer stripe paver blocks production line500*250mm, 600*300mm, 400*200mm
stripe block tiles, stripe stone tiles
KBJX single layer stripe paver blocks production line
(stripe paver machine, stripe paving making machine, stripe stone machine, stripe block making machine)
-- high effiency, 2500pcs per shift
-- single layer, high density, high tightness
-- interlocking in paving
Raw material for KBJX single layer stripe paver blocks production line
Raw materials |
Specification |
Ratio(kg) |
Notes |
Cement |
common |
50 |
|
Additive |
Water-reducing agent |
0.5~1.0 |
optional |
Fly ash |
Should be qualified |
10~30 |
optional |
Stripe pavers / stripe blocks are made by two machines, tile making machine + striping machine = KB-125E/500 + KB-125TWA
KB-125E/500 specification:
| Equipment type | Model 500 |
| moulding speed | 5-6pcs/min |
| main frame power | 7.5kw |
| main frame weight | 7T |
| external dimension | 3300*1680*2700mm |
KB-125TWA specification:
| External dimension | 3000*880*1580mm |
| Grinding head diameter | Ø338mm |
| Cutter blade diameter | Ø200mm |
| motor power | 21.8KW |
| Equipment | pump or tap water |
| weight | 3.5T |
Total production line picture for KBJX single layer stripe paver blocks production line
equipments composed for KBJX single layer stripe paver blocks production line
| 1 | Moulding machine | 1 set |
| 2 | constant feeder machine | 1 set |
| 3 | blender | 1 set |
| 4 | elevator machine | 1 set |
| 5 | air compressor | 1 set |
| 6 | stripping machine | 1 set |
work flow of KBJX single layer stripe paver blocks production line
Work flow: Elevating--- Mixing --- Fixed-quantity filling --- Pressure forming --- Mould unloading --- Forming tiles --- Onto the tiles shelf ---Maintenance (24 hours) --- Stacking --- Natural maintenance --- Ink jetting --- Finished products.
finished stripes
Multi-functional samples of tiles by chaning mould
Factory:
for details information, pls kindly feel free to contact following:
