Help CenterForklift Attachment Hydraulic Block Clamp
Related Products
forklift attachment hydraulic block clamp
efficiently handles cubic goods such as blocks,cement bricks
easy and safe operation
Forklift Hydraulic Concrete Block Clamp
Function
Block clamp can efficiently handle various types of solid, regular cubic goods under normal temperature. Widely used in construction material, metallurgy industries for handling concrete blocks, cement bricks, carbon cubes, etc. The high structural strength and durability ensure the safe, productive application and long service life.
Features
1. Proven durable T-beam arm aluminium frame construction.
2. Superior arm-slide bearing for extended service life.
3. Regenerative hydraulic valving for optimal arm speed.
4. Excellent driver visibility.
Options
*Custom opening ranges
*various material facing arm
*various mounting class available.
*slip-on arm
*load backrests
| Name |
Capacity/ Load Center (kg@mm) |
Type |
Mounting Class |
Opening Range E (mm) |
Arm Height H (mm) |
Arm Length L (mm) |
Frame Width B (mm) |
Overall Height(mm) | Weight(kg) |
Effective Thickness (mm) |
Horizontal Center of Gravity (mm) |
| Forklift Block Clamps | 2700/500 | CKS30D-001A | II | 290-1610 | 128 | 1100 | 1016 | 710 | 500 | 145 | 220 |
| 2700/500 | CKS30D-002A | II | 290-1610 | 242 | 1100 | 1016 | 710 | 550 | 145 | 220 | |
| 2700/500 | CKS30D-003A | II | 290-1610 | 128 | 1000 | 1016 | 710 | 490 | 145 | 211 | |
| 2700/500 | CKS30D-004A | III | 290-1610 | 128 | 1100 | 1016 | 710 | 500 | 152 | 220 | |
| 2700/500 | CKS30D-005A | III | 290-1610 | 242 | 1100 | 1016 | 710 | 550 | 152 | 220 | |
| 2700/500 | CKS30D-006A | III | 290-1610 | 128 | 1000 | 1016 | 710 | 490 | 152 | 220 | |
| 2700/500 | CKS30D-007A | III | 290-1610 | 242 | 1400 | 1016 | 710 | 650 | 152 | 250 |
