Specifications
1.Wire dia:5-12mm2.Mesh aperture:100*100-300*300mm
3.Mesh width:2.5m
4.ISO9001&CE
Composition of the reinforcing wire mesh welding machine Machine | ||
Items |
Name of each parts |
QTY/SET |
1 |
The Welding Machine |
1 |
2 |
Cross Wire Auto-Falling System |
1 |
3 |
Mesh Traction Device |
1 |
4 |
Operation Control Cabinet |
1 |
5 |
Welding Control Cabinet |
1 |
6 |
Equipment Operation and Maintenance Manual |
1 |
7 |
Spare parts box |
1 |
Technical Parameters of reinforcing wire mesh welding machine
Items |
Description |
Detailed |
1 |
Type |
DNW-CNC2500-Q/P |
2 |
Welding Speed |
30-40Times/Min. |
3 |
Mesh Width Range |
1000mm-2500mm (It can be adjusted) |
4 |
Mesh Length Range |
3000mm-6000mm (It can be adjusted) |
5 |
Cross Wire Spacing |
≥50mm (It can be adjusted) |
6 |
Line Wire Spacing |
≥100mm (It can be adjusted) |
7 |
Cross Wire Diameter |
5-10mm |
8 |
Line Wire Diameter |
5-10mm |
9 |
Max. welding Range |
12mm+12mm |
10 |
The Number of Welding Spot |
26 pieces |
11 |
Welding Material |
Low Carbon Cold Drawing Wire, Galvanized wire, Cold rolled ribbed. Smooth surface, no rust, no stone drawing agent, a smoke-free marks, free from water stains, no spots scar. |
12 |
Crosswire Feeding Method |
Pre-cut
|
13 |
Line wire Feeding Method |
Pre-cut
|
14 |
Operation Control Method |
PLC Programming Control |
15 |
Rated power |
125KVA*13 (Water Cooling) |
16 |
The Allowed Fluctuation Range for Power |
±10% |
17 |
Supply Voltage |
380V |
18 |
Current frequency |
50HZ |
19 |
Gas Source |
≥0.8Mpa 3CBM/Min |
20 |
The Machine Size |
L6000mm*W3250mm*H2300mm |
