Specifications
1. Iron Ore Smelting Process2. Great processing ability
3. High automatical operation
Iron Ore Smelting Process
1.General Introduction of Iron Ore Smelting Process:
Iron Ore Smelting Process mainly consists of such four parts as cylinder, magnetic system, cell and transmission parts. Cylinder is made of 2-3mm welded and bent stainless steel and the terminal cover is forged aluminum plate which is connected with stainless bolts. The motor drives the cylinder to go round and round through decelerated machine. The magnetic system is open and put in the cylinder. The magnetic piece is installed on the bottom plate with stainless bolt, the axis of magnetic yoke spreads out of cylinder, and there is cranks which are fixed on the end of axis. The angle of magnetic system can be adjusted by pulling the crank, and be fixed with push rod. The working area of cell is made of stainless steel plate, and the other parts of frame and cell adopt common welded steel.
2.Working Principle of Iron Ore Smelting Process:
The mineral slurry flows into the cell through box feeder, the mineral particle is loose under the function of water flow of feeder water pipe when they flow into the cell. Affected by magnetic field, the magnetic particle swarm together and form magnetic cluster or chain. With the magnetism of mineral slurry, the magnetic cluster or chain moves toward the magnetic pole, and is absorbed to the cylinder. Because of the polarity of magnetic pole, the revolving directions alternate constantly, and remain fixed when it is working. When the magnetic cluster and chain go round and round along with the cylinder, the mingled gangue and other non-magnetic ore fall down due to the mixing phenomena produced by alternation of magnetic poles, and it is concentrate that is absorbed to the cylinder surface. The concentrate moves to the end of magnetic system where the magnetism is weakest along with the revolving cylinder, and is discharged into concentrate tank by the current ejected by the discharging-ore pipe. The non-magnetic or weak magnetic remained are discharged along with the mineral slurry, and they are gangue.
3.Main Features of Iron Ore Smelting Process:
The magnetic system of Iron Ore Smelting Process integrates good-quality iron-oxide body materials with rare earth magnetic steel; the average magnetic induction intensity of cylinder surface is 100-600mT. According to the needs of customers, the Iron Ore Smelting Process can be co-current, half-countercurrent, countercurrent, and so on. The Iron Ore Smelting Process has the advantages of simple structure, big processing volume, convenient operation and easy maintenance, etc.
The Iron Ore Smelting Process is applicable for wet mineral separation of such materials as magnetite, pyrrhotine, roasted ore and ilmenite, etc. and it is also applicable for iron removal working of such materials as coal, nonmetal and building materials, etc.
The Mining Equipments flow produced by our company can provide you with all-around technical support. According to different customers and different mine, my company design different beneficiation complete sets of equipments for you.
We can offer complete sets of slecting iron, gold, copper, lead, tungsten, etc equipments.
We also offer single machine of above and have supplied complete set of mechanical equipments for the clients all over the world.
