Help Centerce DaShan High Grade Organic Fertilizer Guniting Granulator
Related Products
-
China Dashan Organic Manure Production LineUS$ 12,600 - 180,000MOQ: 1 Set -
China Dashan Pig Manure Organic Manure Processing EquipmentUS$ 12,600 - 180,000MOQ: 1 Set
-
High Quality Double Roller Squeezing Granulator SupplierUS$ 2,680 - 18,600MOQ: 1 Set
-
High Efficient Fertilizer Granulator TechniqueUS$ 5,695 - 68,000MOQ: 1 Set
-
Late Model Amino Acid Method Granulation EquipmentUS$ 5,695 - 68,000MOQ: 1 Set
Specifications
Place of Origin:CN;HEN;Brand Name:DASHAN;Type:Granulator; Certification:CE/ISO9001; Name;organic fertilizer guniting granulator
organic fertilizer guniting granulator
Henan Dashan Mining Machinery Co., Ltd.
The organic fertilizer guniting granulator is the key equipment in compound fertilizer industry.
It is used for producing the high, medium, low concentration of compound fertilizers, the shell used a special rubber-lined, resist corrosion, anticorrosion, a high intensity of being ball, quality of the appearance is good, operation and maintenance are convenient.
1. Introduction of organic fertilizer guniting granulator:
Rotary drum Granulator is very versatile pieces of equipment that can process a wide array of materials. The equipment is typically used for high capacity applications and usually requires some type of recycle depending on the product specifications. Drum Granulators are used when an Agglomeration - Chemical Reaction Process is required.
2. organic fertilizer guniting granulator application:
As the one of the key equipments in fertilizer industry, drum granulator is applicable to cold, heat, and guniting and ammoniated granulation and big scale fertilizer production of high, medium and low concentration.
3. organic fertilizer guniting granulator advantages:
The cylinder body adopts special stainless steel or rubber plate lining structure. It can remove scar and peel burl automatically It has the advantages of high intensity of granule, high production, erosion proof, abrasion proof, low energy consumption, long service life, convenient operation and maintenance etc.
Technical parameters of organic fertilizer guniting granulator;
Specification(m) |
Shell |
Capacity(t/h) |
Power(kw) |
|||
I.D.(mm) |
Length(mm) |
Slope(°) |
Rev(r/min) |
|||
Ø1.4×4 |
1400 |
4000 |
2.5 |
15.05 |
5 |
11 |
Ø1.6×6 |
1600 |
6000 |
2.5 |
12 |
7 |
15 |
Ø1.8×6 |
1800 |
6000 |
2.5 |
11.5 |
8 |
15 |
Ø2.0×7 |
2000 |
7000 |
2.5 |
10.8 |
14 |
30 |
Ø2.2×8 |
2200 |
8000 |
2.5 |
10.85 |
20 |
37 |
Ø2.4×8 |
2400 |
8000 |
2.5 |
9.6 |
25 |
55 |
Ø2.8×8 |
2800 |
8000 |
1.5 |
6.5 |
35 |
90 |
Henan Dashan Mining Machinery Co., Ltd. Organic fertilizer guniting granulator advantages
The cylinder body adopts special stainless steel or rubber plate lining structure. It can remove scar and peel burl automatically It has the advantages of high intensity of granule, high production, erosion proof, abrasion proof, low energy consumption, long service life, organic fertilizer guniting granulator convenient operation and maintenance etc.
Remark: If the formulation, process and raw material are different, it will affect the yield, grain rate and the diameter of the grain.
