Help CenterLaser Wire Diameter Measurement
Related Products
-
Cable Diameter Micrometer (Model: LDM-25)US$ 1,500 - 2,000MOQ: 1 Piece -
Outside Diameter Gauge (Model: LDM-50)US$ 1,500 - 2,000MOQ: 1 Piece
-
Cable Outside Diameter Gauge (Model: LDM-25)US$ 2,400 - 3,000MOQ: 1 Piece
-
Outside Diameter Micrometer (Model: LDM-50)US$ 1,500 - 2,500MOQ: 1 Piece
-
Laser Outer Diameter Gauge (Model: LDM-25)US$ 2,500 - 3,000MOQ: 1 Piece
Mainly used in measuring the outer diameter of pipes, wires and rods, such as communication cables, plastic wires, electric cables, optic fibers, enameled wires, aluminum plastic pipes, steel pipes, fibers; It allows both online and offline measuring with feedback control, remote-end display, out-of-tolerance alarm and communication with PC.
Characteristics
1. Adopt laser scanning and noncontact measurement, with no damage to the object
2. Adopt high speed data processing technology with fast sampling, high precision and reliable performance
3. Capable of PID feedback control system
4. Capable of communication with PC or PLC with RS485/232 communication port
5. Capable of far-end display with a second monitor and 200 meters cable
6. Capable of relay deviation actuating alarm.
Parameter
Measuring Range |
0.20-45.00mm |
Measuring Precision |
+/-0.001mm |
Scanning Speed |
200T/S |
Working Voltage |
AC220V |
Ambient Temperature |
Under 50 |
Display Controller (Model: DDC-5)
