DZ603-24 Three Phase KWH Meter Test Instrument

DZ603-24 Three Phase KWH Meter Test Instrument thumbnail-1
DZ603-24 Three Phase KWH Meter Test Instrument photo-1
US$ 2,000 - 31,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
SMS
Model Number:
DZ603-24
Contact Supplier Request Quote Chat Now
SMS Electric Co., Ltd. Zhengzhou
Payment & Shipping
Payment Methods:
Port of Shipment:
As per your request
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name SMS
Model Number DZ603-24
Power Electronic
Usage Other, Energy meter test/calibration

Specifications

1. 3-60 meter positions
2. Accuracy class:0.05
3. Certificate: ISO 9002
4. Can test both single-phase and three-phase meters







Product Description





Three Phase KWH Meter Test Bench



1-      Applied to test all kinds of single and three-phase energy meters, whatever electronic or mechanical type or electromechanical, active meter or reactive meter.

2-      Simultaneously test meters with same specifications but different constants

3-      operation mode:SMS special keyboard and SMS PC software control

4-      display mode: error indicator on each meter position / PC monitor

5-      support all test items covered by related regulations, include:
 no-load test/ start test/ basis errors test/ voltage influence test
 meter constant test/ meter reverse turn test/ energy counting test etc.

6-      The electric-driven mechanism controls elevate /lower all of scanning heads

7-      simultaneouslyfull-automatic current/voltage measuring range switching

8-      output voltage and current adopts soft- stop

9-      auto-alarming protection against output voltage short circuit and current open circuit

10-  auto capturing the black dot on the rotor before starting test and no-load test

11-  Harmonic setting

12-  Distortion degree measurement

13-  Waveform display

14-  support reverse phase-sequence output

15-  programmable Voltage/ current/ frequency and phase angle

16-  support bar code input, error curve, error limit setting , multi-mode calibration plans setting and equipment authoriy by PC software

17-  support data processing and verification certificate printting with customized table format

18-  Self- testing, PC software could read out standard meter tested data, and calculate power stability, testing symmetry, display vector chart and waveform, testing harmonic analysis distortion.



INDEX

  1. Voltage output ranges:57.7V,100V,220V,380V
  2. current ranges:1mA,5mA,10 mA,25 mA,50 mA,0.1 mA,0.5 mA,1.0A ,2.5 A,5 A,10 A,20 A,50 A,100 A,
  3. voltage/current adjusting resolution:0.01% × range
  4. voltage and current adjusting scope: (0-120%)×range
  5. phase scope:0-359.9 º, adjusting contiunally.
    resolution is 0.01 º,accuracy: ±0.05 º
  6. frequency output scope :45.00-65.00Hz,adjusting continually.resolutions is 0.01Hz,accuracy: ±0.05Hz
  7. Output current and voltage stability:<0.05%,output power stability:<0.05%
  8. Output voltage and current distortion:<0.5%
  9. Output power: voltage: 280VA/phase
                current: 450VA/phase
  10. Accyracy class:0.05,0.1
  11. Power supply:3×220V or 1×220V ±10%,AC50Hz
  12. Meter position:12,16,24 optional
  13.
    Packaging & Shipping



    1. Packing & Shipping

          Packed in Plywood case

          Deliver the goods within one month after receiving the prepayment




    Our Services

      1. We can produce the single phase meter test bench/single phase energy meter instrument/single phase electricity meter test equipment according to client's requirement.

      2. Good after-sale service, and good quality.

      3.  All our products can test all items such as Per IEC and ANSI


    FAQ

      1.  What is the advantages of your products?

            Thanks for your inquiry. Our products' advantages is that all products achieve the standard of IEC and ANSI.

            And our goods have been exported to many countries in the world, such as Korea, India, Russion, Pakistan, Vietnam ans     so on. The quality is excellent that it wins lot reputation for us.

       2.   What is the shelf life for your products?

             Thanks for your consideration. The shelf life of our products is 3 years. (Our company is responsible for the repairing and maintaining free of charge)

       3.   What terms of trade your company accept?

             Thanks for your consideration. Our company accepts T/T, L/C, Western Union. Thanks for your understanding.
