Linyi Shining Asia Industry CO, egg laying cement block making machine.
QT40-3A Moving Brick Making Machine Information and Price
Date:2013-09-23
1. Price
Item |
Quantity |
Total Price(USD) |
Host brick machine |
1 set |
4000 |
One mould |
Free for you |
|
Some spares |
Free for you |
|
tools |
Free for you |
|
JD350 Mixer |
1 set |
700 |
Optional Part | ||
Extra Block Mould |
1 set |
580 |
2. Production Capacity
QT40-3 Theoretical Production capacity |
|
|||
Size(LxWxH) |
Pcs/Mould |
Pcs/ Hr |
Pcs/ 8 Hr |
|
400X150X200 |
5 |
600 |
4800 |
|
400X200X200 |
4 |
480 |
3840 |
|
400x100x200 |
7 |
840 |
6720 |
|
400X250X200 |
3 |
360 |
2880 |
|
3. QT40-3A block machine main technical parameters
Dimension of host machine |
1800×1400×1100mm |
Vibration force |
35.5KN |
Moulding period |
25S |
The size of the pallet |
No need pallet |
Capacity |
5.2KW |
Weight of the machine |
0.8 T |
Voltage |
380V |
4. JD350 Mixer parameter
Maim Technical Specifications | |
Discharging capacity |
0.35 m3 |
Feeding capacity |
0.56 m3 |
Productivity |
≥4m3/h |
Max. aggregates diameter |
80mm |
Mixer power |
7.5 KW |
Diameter |
1200mm |
Wegiht |
0.52Ton |
Price Terms
1.factory price
2.Payment terms:30% as down deposit by T/T ,70% as the balance paid by T/T before loading
3.Validity:Two weeks
4.Delivery: 20 days upon receipt of down payment.
