Application range:
1. Plastic packaging inflatable toys raincoats or umbrellas
2. Purse handbag stickers stationery embossed leather
3. Footwear trademark cloth car seat category Flower
4. Any such as any PVC or PVC content in more than 30% of plastics welding
5. blister- paper or blister- blister package
Character:
1. Most apply for APET,PETG,GAG etc Eco-friendly blister packing,tooth brush packing,soft crease plastic box making,all material which need welding and cutting simultaneously,all can work by this machine.
2. Double-direction automatic slipway,come-and-go or continuous delivering the mould,accurate-orientation, error + 20 um.
3. Adjustable cutting pressure 1-50 tons,stable and realible in output,firm in structure.
4. Adopting high sensitive anti-sparkle device NL5557 to avoid damaging the mould efficiency.
5. Operation mode: oil+pneumatic or pure-pneumatic.
Technique specifications
Model |
HR-5000WT |
Power |
5000W |
Voltage |
220V/380V 50/60HZ&customized |
Frequency |
27.12MHZ |
Input power |
8KVA |
Rectifier |
SILICON DIODE |
Oscillation tube |
7T85RB |
Max pressure |
5T/10T |
Gap between electrodes |
200MM |
The moving distance of active horn |
150MM |
Size of upper electrode |
300*400 |
Size of lowwer electrode |
300*400 |
Range of tempreture |
30~200C Adjustable |
Welding time |
0~10S Adjustable |
Productivity |
<5000times/8h |
Net weight |
1T |
Overall dimension |
1920*1200*2060mm |
SAMPLE
WELD&CUT AT SAME TIME
PET CLAMSHELL
Mould and sample photo:
Packaged Views:
CE certificates:
