Automatic sliding way Radio Frequency Welding and cutting machine
Application: Specialize for the plastic product with need to be welded material together and cut the extra edge out simultaneously. This kind of machine can be also called as hf simultaneous welding and cutting machine.Mainly apply for welding and cutting APET,PETG,GAG, Double side clamshell,blister+cardboard,leather,OPP,PU and many other environment-friendly materials.
product categories
We have divided our radio frequency synchronous welding and cutting machines into several different product categories;
1.Automatic turntable radio frequency synchronous welding and cutting machine(with/without robot)
2.automatic sliding way radio frequency synchronous welding and cutting machine
3.manual shuttle way radio frequency synchronous welding and cutting machine
4.Double heads radio frequency synchronous welding and cutting machine.
5.manual turntable radio frequency only welding machine(with/without robot),
Stable frequency
In strict accordance with the requirements of "Committee on Radio Interference" (CISPR).
Oscillation Frequency: 27.12/40.68 MHZ. With a cycle stabilizer and a device for suppression of leakage of the magnetic flux.
Minimal interferes with the outside equipment.
European model squarness high frequency vibration box to support more realible and stable in output.
Spark restrains
With NL5557 high sensitivity spark suppression circuits, Accurate detection of the imbalance current. Can instantly cut off
the supply of the oscillation loop to restrain the sparks to protect the mold, raw materials and products. At the same time
warning lights will send you the alert.
Oscillation current regulation
Different output power based on product size and thickness is available.
You can control the welding and guarantee the homogeneity of the quality
Welding mould(die)
Radio frequency machine must work with radio frequency welding die. More than getting perfect welding and cutting
effect,we do some special treatment on the welding die by ourselves to make it more durable. Our client can use it
for about 10 million times without any replacement of the down mould.
Multi-working positions.
Automatic turntable working-plate with 3~6(optional) working positions and circum rotation.
installed with Taiwan motor drive to support precision decollator,ac-orientation,error+10um.
Can have robot to fetch the finished products out off machine.(optional part)
Security
With over-voltage, over-current protection devices, can automatically cut off the supply to protect the oscillation tube
and the rectifier, at the same time avoid frequency drift.
Technical parameters:
| Model | HR-5000WT |
| Power | 5000W |
| Supply power | 3P 220V/380V 50Hz/60Hz & Customized |
| Frequency | 27.12Mhz |
| Input supply | 8KVA |
| Rectifier | Silicon Diode |
| Oscillation tube | 7T85RB |
| Max pressure | 5T |
| Gap of electrodes | 200MM |
| Distance of active horn | 150MM |
| Size of upper electrode | 300*400MM |
| Size of buttom electrode | 350*450MM |
| Temperuture Scale | 20~300 Adjustable |
| Welding time | 0~10S Adjustable |
| Productivity | Equal or less 4000times / 8 hours |
| Net weight | 1T |
| Packing Dimension | 920*1200*2060MM |
Welded samples:
Mould and sample photo:
1. Customer's site installation, training & maintenance available
4. Recommend equipment of top choice based on your requirements for product;
5. Examining mold drawings on your behalf to confirm optimum structure size meeting high frequency process;
6. Providing assistance in manufacturing and modifying tools;
7. Our engineering instruction will guarantee your productive manufacturing of top-quality products.
We use Ply-wood case for packing machines, it will meet export standard like safty, protection requirment
and durable performance in long time shipping by sea or by air.
We can provide non-solid wood packing decleartion, our packing no need fumigation.
Questions 01.
How Do You Pack the machines
RE: Our machines will be packed into wood case, (we will process the wood case and make sure it is exporting standard, and no need addtional fumugation)
Questions 02.
Is it difficult to install the machine ?
RE: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine;
you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get install videos, and install instructions from us.
It will be an ABC thing to install machines at your side.
Questions 03.
How Does Customer Use the machines
RE: We will provide you operation manual and diagram of machine in English.
For automatic machine and custom machine, we will provide operation videos to you.
Questions 04.
Does the machine need compressed air ?
RE: Generally speaking, if your factory with compressed air source, then connect to machine.
If not, please buy a 2Psi -5 Psi air compressor.
If customer request to use Hydraulic pressure, please inform us when put an order.
Questions 05.
Does the machine power voltage meet buyers' factory power source?
RE: We can make machine with voltage like:
frequency: 50 - 60HZ Phases: single phase / 3 phases
Voltage: 110V / 220V / 380V/ 415V/ 440V / On request
Please kindly inform us what frequency/phases/voltage you want, when you put order to us.
Questions 06.
Could you make die / mould for me, if I buy machine from you?
RE: We design and make moulds up to product sample or drawings, we charge the mould price at facory cost price.
Questions 07.
Can I visit you factory to check machines on-site ?
RE: We are manufacturer, and we welcome customers to visit our factory.
We located in Shenzhen, China; you may come to us by following:
a) Via. Hongkong to Shenzhen :
please reach check points between Hongkong and Shenzhen, we will arrange to pick you up from Check-point like Shekou, Lohu
b) Via. Guangzhou to Shezhen;
you may come by train to Shenzhen Luohu Station / Shenzhen North Railway Station.
we will arrange to pick you up from station.
c) Via. Shenzhen Airport :
Please inform us your flight number and contact information before you come, we will meet you at airport.
Questions 08.
What Should I bring when I visit your factory?
RE: For special product design and develop, we request you bring a piece of testing material, you can test on our machines on-site.
For common product, it is enough to show us product pictures or drawings.
CE certificates:
