Fume Extractor for Medical Work With CE

Fume Extractor for Medical Work With CE thumbnail-1
Fume Extractor for Medical Work With CE photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Pure-Air
Model Number:
PA-500FS
Contact Supplier Request Quote Chat Now
Dongguan Pure-Air Tech Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
HONGKONG
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Pure-Air
Model Number PA-500FS

Specifications

PA-500FS Air Cleaner used on medical work laser fume & toxic, with CE certification

PA-500FS  Fume Extractor for Medical Work with CE

1. Strict welding and painting technology achieve to high tightness and corrosion resistance cabinet.

2. Specific sound-absorbing materials reduce operating noise to improve operation efficiency.

3. European imported low-power blower, new high pressure technology, small size, brushless design & electronic speed adjustment.

4. Our fume extractor has PWM speed control, according to the amount of dust to achieve precise adjustment. Control system is also equipped with sound and light alarm, prompt to clean or replace the filter.

5. PA-500FS filtration system consist of four parts, they are metal filter, F5 class pre-filter, HEPA main filter and gas filter.

(a). Well-proportioned holes to ensure that large dust particles are trapped on the metal filter, to prevent them block the pre-filter.

(b). F5 class pre-filter comprised by cotton and metal mesh, full-thickness adhesive, can be adsorbed middling particles in the air to avoid main filter is blocked.

(c). Main filter consists of efficient HEPA element, in independent tests, these filters remove 99.997% of all particles above 0.3 microns and 95% down to 0.01 micron.

(d). Our fume extractor's gas filter layer formed by the chemical materials can effectively remove harmful gases and pungent odor in the air.

6. Fume extractor's Filter Data
Filter Elements Data
Item
Technical Data
Remark
Pre-filter
F5 class
PP pre-filter.
Main-filter
H14 class HEPA
Filter can remove 99.997% of all particles above 0.3 microns and 95% down to 0.01 micron.
Gas-filter
Chemical material
Chemical molecular, Oxidant & Active carbon adsorb noxious gas.
Average filtration rate
≥99.7%
It will be a little fluctuation according to different materials.



7. Fume extractor'sTechnical Paremeters

Blower Technical Data
Item
Technical Data
Remark
Running period
more than 30,000h
One year guarantee
Max. air flow
500m³/h
Electronic speed control
Input capacity
345W
Low capacity
Air pressure
2800pa
High pressure
Running sound
≤60dBA
Low sound volume
Input power
110/220V, 50/60Hz
International standard



Equipment Data
Item
Technical Data
Remark
Fume & dust inlet
100mm
Single fume inlets, include one/two set fume extract tube
Fresh air outlet
100mm
Trapezoid hole
Machine weight
56KG (N.W.)
Machine with all elements
Dimension
450*450*900mm
Machine size
Package dimension
530*530*1020mm
Packed by plywood crate
