Help CenterAluminum Electrolytic Capacitor 88-108mfd 275V CD60 Capacitor
Related Products
-
Aluminum Electrolytic Capacitor 100uf 275V CD60 CapacitorUS$ 0.5 - 4MOQ: 100 Pieces -
Aluminum Electrolytic Capacitor 200uf 275V CD60 CapacitorUS$ 0.5 - 4MOQ: 100 Pieces
-
Aluminum Electrolytic Capacitor 300uf 275V CD60 CapacitorUS$ 0.5 - 4MOQ: 100 Pieces
-
Rosh Run Capacitor 3uf Capacitor With Hot Saler /super Quality /best Price ,3uf Capacitor Supply ChinaUS$ 0.5 - 4MOQ: 100 Pieces
-
Aluminum Electrolytic Capacitor 50uf 250V CD60 CapacitorUS$ 0.5 - 4MOQ: 100 Pieces
Specifications
1.Aluminum Electrolytic Capacitor2.Good insulation
3.High performance
4.Good sealing and Long life
5.High strength
Features
Aluminum Case, Mositure and Oil Resistant Voltages from 110V AC to 330V AC UL Recognized Capacitors.
General Specifications
Operating Temperatrure:-40 to +70 °C
Voltage Range :110~330V AC
Capacitance Range :21~1280μF
Capacitance Tolerance:-0%~+20%
Operating Frequency:50~60Hz
Case Size:8 Standard Size from
1.437 " x2.750 "~2.562 " x4.375"
Termination:
1/ 4"Quick Disconnect Terminals(Std.)
Performance Specification:
Meets Requirements of EIA-463-A
Starting and running of single phase motors in
alternating current usage.
Product Description
This kind of the capacitors are developed and researched according to standard of American Electronics Association(ANSI/EIA-463). The external case of the capacitor is made of bakelite plasticized that its character are not only good insulating resistance and strong resistance damaged bus also protecting electro-liquid as good sealed feature. It is popular used for the super AC application as good life, higher degree of reliability and stability.
| Item | Item |
| Operating temperature range | -25~+55°C |
| Rated voltage range | 110~330VAC |
| Nominal capacitance range | 25-1000μF |
|
(20°C,120Hz) Nominal capacitance tolerance |
±10%,±15%,±20% |
| Dissipation factor(20°C,120Hz) | Tgδ≤0.15 |
| Surge voltage | Capacitor leads to the connection between the media should be able to withstand the test voltage 1.2Un lasted 2S, testing should not occur during the breakdown flashover |
| Load life | Un less than 160V power capacitors by 1S, no electricity 1min test for Un ≥ 160V capacitors , according to the 1S -energized power and 2min test , Test duration 500h, including power and unreasonable time , test time from power Container since the beginning of the applied voltage , test voltage should be 0.85 times the maximum voltage , The maximum allowable capacitance change of 15 % of initial value . |
|
Insulation level test for capacitor |
Capacitor between terminals and case insulation should withstand ≥ 2KV -frequency test Voltage , the time for 10S, breakdown or flashover should occur |
|
Surge voltage |
1.2 times the working voltage applied for 2 seconds , not breakdown or flashover . |
| Circuit and housing to withstand the voltage between | Failure, can withstand 10 seconds at 2000 volts , not breakdown or flashover |
