Glass break sensor
Specification:
Power 9~12VDC
Current (static state) 5mA
Current (alarm) 25mA
modulation ASK or FSK
RF 433.92 or 315MHz
Ocillastor (ohm) 1.8(1.5) or 3.3/4.7
Red LED Indicat alarm signal
Temperature -10~50c
Casing ABS fire resistance plastic
Size 90x66x25mm
Introduction:
The manufacture process is by the quality detection, to make sure the operation and durable function. The detector with audio checking, all frequency chock analysis, when there is high-pressure, can be sure the special sound by the glass break. With constant adjusting the sensitivity to avoid the false alarm, it is the most advanced detector in the market.
Range:
It can be used in the flat, intensify and cascade glass. The detector is used with glass cabinet, glass door and window. Before using the detector please detect carefully. Notice: The detector can not connect the panel 24 hours zone.
Functions:
- Mollusk drive, digital signal process 8/12 bit microprocessor (8Mhz).
- High frequency sound pressure detection.
- All sound frequency 7 kinds frequency signal and impact analysis include inferior sound press analysis.
- Digital filtration RFI/EMI rejection.
- Particular mike design.
- Adjust the sensitivity by hand can avoid the false alarm.
Choose the installation place:
The right place is the key element to the detector.
It can install on the ceiling, near the glass and opposite the glass, forbid installation the things which have noice such as bell, fan, compressor and machine.
Make the mike be opposite to the glass with no obstruction and in the best angle. Do not install the detector on the opposite wall. (picture 1)
Installation:
Fix the detector on the proper target, connect the Transformer. adjust the sensitivity, check the detector. If not presetting the code to match the main alarm panel, please refer to the code diagram
Adjust the sensitivity
To avoid false alarm ,please set the sensitivity as follow:
Use a plastic ruler to flap the glass, the red light will not light. If the red LED is bright, it means the sensitivity is too strong, you revolve VR cathode to adjust the sensitivity. Repeat until the red light is not bright. Check the sensitivity if it can alarm normally: flap the glass hard, if the red LED light is bright, means alarming, if not, please adjust the sensitivity to high. When setting the sensitivity, it should be the same as the outside condition. For instance: If you want to arm at night, when set it please put down the curtain. Notice: Do not adjust the sensitivity too high in case of false alarm.
Test by glass frequency rate: Take the tested glass in the far place, press “ PUSH” to enable to have glass broken frequency. The red LED lights, if not, please adjust the sensitivity in high position.(revolve VR cathodeclockwise)
Packaging and Shipping
Packaging details : whitebox or colorbox
Delivery details : within 7-10 working days after receipt of your deposit
