Commercial water source heat pump
Geothermal/Ground Source Heat Pump /water to water heat pump
Blueway 2013 new ground source heat pump allows you to combine a water based heating system with a modern heat producing device. It saves energy consumption up to 75% compared with electric heaters.
The ultra quiet design makes the whole compressor and heat pump system on a floating plate, leads to a compete isolation from the heat pump bottom, and reduce vibration and noise at the most extent. That is to say, Blueway new brine to water heat pump is ideal for indoor installation.
Products Features
1) Base frame and external panels made of galvanized powder coated steel
2) Compact structure and good demount ability
3) Reliable compressor with environment friendly refrigerant
4) Intelligent controller with possibility of remote control available
5) Wide rang of capacity selection, from 6KW to 50KW.
6) Stable water flow switch available
7) Multi-functional products protection. High pressure and low pressure, overheating, overload, anti-freezing,
8) The units can work stable all year around.
Products specification:
| Specification-Water Source Heat Pump | |||||||||
| TECHNICAL DATA | DWW-06HA | DWW-08HA | DWW-10HA | DWW-13HA | DWW-16HA/3 | DWW-20HA/3 | DWW-30HA/3 | ||
| Heating | Nominal capacity | KW | 7.2 | 9.55 | 10.74 | 14.3 | 17.5 | 23.4 | 33.2 |
| Power input | KW | 1.42 | 1.9 | 2.16 | 2.75 | 3.38 | 4.46 | 6.38 | |
| COP | W/W | 5.08 | 5.03 | 4.97 | 5.2 | 5.18 | 5.25 | 5.2 | |
| Cooling | Nominal capacity | KW | 6.5 | 7.55 | 8.45 | 12.7 | 16.7 | 20 | 30.4 |
| Power input | KW | 1.58 | 1.88 | 2.16 | 2.98 | 3.98 | 4.65 | 7.1 | |
| EER | W/W | 4.12 | 4.01 | 3.91 | 4.26 | 4.20 | 4.30 | 4.28 | |
| DHW | Nominal capacity | KW | 6.35 | 8.32 | 9.5 | 12.5 | 15.4 | 20.6 | 37.6 |
| Power input | KW | 1.69 | 2.26 | 2.56 | 3.25 | 4.05 | 5.28 | 11.12 | |
| COP | W/W | 3.76 | 3.68 | 3.71 | 3.85 | 3.8 | 3.9 | 4.25 | |
| Power supply | V/Ph/Hz | 220-240/1/50 | 380-415/3/50 | ||||||
| Max. water-outlet temperature | °C | 58 | |||||||
| Refrigerant type | R410A | ||||||||
| Compressor type | Rotary | Scroll | |||||||
| Heat exchangers | Coaxial Heat Exchanger | Plate Heat Exchanger | |||||||
| Dimensions (Net) | HxWxD | mm | 982x606x634 | 982x606x634 | 982x606x634 | 982x606x634 | 982x606x634 | 982x910x634 | 982x910x634 |
| Dimensions (Packing) | HxWxD | mm | 1110x715x715 | 1110x715x715 | 1110x715x715 | 1110x715x715 | 1110x715x715 | 1110x1020x715 | 1110x1020x715 |
| Net weight | kg | 130 | 138 | 140 | 135 | 138 | 150 | 170 | |
| Gross weight | kg | 135 | 143 | 145 | 140 | 143 | 160 | 180 | |
| Noise level | dB(A) | 47 | 47 | 47 | 48 | 48 | 53 | 56 | |
| Container loading | 20' GP (units) | 48 | 48 | 48 | 48 | 48 | 48 | 48 | |
| 40' GP (units) | 96 | 96 | 96 | 96 | 96 | 96 | 96 | ||
| 40' HQ (units) | 96 | 96 | 96 | 96 | 96 | 96 | 96 | ||
|
NOTES: Capacities and power inputs based on the following conditions: - Cooling: Water source inlet/outlet temperature 30°C/35°C; User side inlet/outlet temperature 12°C/7°C. - Heating: Water source inlet temperature 10°C; User side inlet/outlet temperature 30°C/35°C. - Domestic Hot Water: Water source inlet temperature 10°C; Water temperature in the tank 40°C (Tank not included). - The flow rate obtained during the test at standard rating conditions in cooling mode is used. | |||||||||
