Rubber Sheathed Flexible Mine Cables
Specifications
1 IEC, ASTM, DIN, BS standard
2 ISO, CCC certification
3 Response within 12 hours
4 Free Sample
5 On time delivery MCP, MYCPT, MYQP,
Flexible Rubber Mining Cable
This product is the rubber sheath flexible cable series used in coal-mining.
It is for rated voltage Uo/U 0.38/0.66 and Uo/U 0.66/1.14kV used in coal mining machines installation equipment to connect power supply. It can be shifted as you like.
Operating characteristics:
1. The rated power frequency voltage U0/U: 0.38/0.66KV, 0.66/1.14KV
2. Permissible operating temperature: -35° C to 65° C.
3. The mininm bending radius is over 6times of cable Diameter
4. The yellow sheath cable should not be exposed in the sun for long
Model and Data
Name |
Rated Voltage |
Core number X cross section |
Application |
Rubber sheathed,flexible Coal cutter cables |
0.38/0.66 |
3*16+1*4+3*2.5 3*25+1*6+3*4 3*25+1*6+4*2.5 3*50+1*6+4*4 |
Connecting various Coal cutters and similar equipment Under the mine shaft |
|
Screened rubber sheathed,flexible coal cutter cables |
0.38/0.66 |
||
Electric driller cables for mine |
0.3/0.5 |
3*25+1*2.5 3*4+1*4 3*2.5+1*2.5+1*2.5 3*4+1*4+1*4 |
Drill connection Under the mine shaft |
Screened electric driller Cables for mine |
0.3/0.5 |
||
|
Rubber sheathed movable and flexible mine cables |
0.3/0.5 |
3*4+1*4 3*6+1*6 3*25+1*16 3*25+1*16 3*10+1*10 3*50+1*16 3*16+1*10 3*70+1*25 |
Power connection of Various movable coal cutter under the mine shaft |
|
Screened rubber sheathed movable and flexible mine cables |
0.38/0.66 |
Yiteng Cable Technology Hebei Co., Ltd
Established Year: 2014
Registered capital of RMB:100,000,000
Factory Area:36,000m2
Manufacturing Capacity per year: 250000km
Number of Employees: 250
Main products:
Bare conductors(AAC,ACSR,AAAC,ACAR,Aluminum Clad Steel Conductor);
Aerial Bundled Cable (ABC Cable);
Power cable,Electrical wire cable,
Armored cables,
Control cables,
Rubber insulated cables, PVC insulated wires and cables,
Battery cables,Instrument cables, Coaxial cables,Flat cables,
Welding cables,House wire,Special Cables etc.
FAQ:
1.Q: Is your company a manufacturer or a trade company?
A: We are cable manufacturer.
2. Q: Where is your factory located? How can I visit there?
A:Our factory is located in Ningjin City, HebeiProvince, China. You can fly to Shijiazhuang airport directly. All our clients, from home or abroad, are warmly welcome to visit us
3. Q: What is your sample policy?
A: Some of our samples are available for free, while others are available at a cost, which will be deducted from the purchase order.
4.Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end.
5. Q: I am very interested in your product, can you sent me your full catalog and pricing list?
A: We can select some popular products for you immediately. Please let us know your requirements so that we can send out the quotation to you.
1. We guarantee to offer new advanced goods.
2. We'd like to send skilled personnel to the installing place to help offer technical consultant, quantity estimation and instruction, installing, preliminary testing,and help start up running; and to answer for any defect of the product found in installing and run testing,if there's something wrong with the product, we'll give our answer within 12 hours and get to the spot within 36 hours.
3.After installaton, We'll send skilled personnel to have the preliminary test and answer for any problems emerged. We take the whole charge of the fee needed in repairing,testing or retesting within the scope of our duty required in contract.
4.During the contract's period of validity,of the project must be started all over again or the goods can not be used at all which is resulted from our faulty goods and improper files or mistakes made by our instructors, we'll change the goods at once without compensation and take charge in all expenses of reinstallation.
Notice:we can produce the product according to customer's requirment.Short delivery time and quotation at once.
