Help CenterSJIA-100Fsjia Sea Food Fruits Freeze Drying Equipment
Related Products
-
SJIA 20 to 100F 0.1-0.72 Drug Lyophilizer Freeze Dryer ManufactureUS$ 10,500 - 15,000MOQ: 1 Unit -
SJIA-200-800FT SJIALAB Series Large-scale Vacuum Freeze DryerUS$ 28,000 - 150,000MOQ: 1 Set
-
SJIA-200-500FTvegetable Freeze Drying MachineUS$ 28,000 - 100,000MOQ: 1 Set
-
SJIA-50F Pilot Vacuum Lyophilizer /freeze DryerUS$ 1,000 - 18,000MOQ: 1 Unit
-
Laboratory Freeze DryerUS$ 1,600 - 2,500MOQ: 1 Set
hot sell freeze dryer machine
SJIA-20F 30F outer size 123 x71 x125CM
SJIA-50F outer size 108 x72 x137CM
SJIA-100F outer size 120x80x192CM
Purpose:
SJIA series vaccum freeze dryer ( In situ) is suitable for laboratory samples of freeze drying test,
and a small amount of production.The machine is with shelf sheating function,using PLC technology
which is accurate temperature control,human-computer interface using LCD screen with curves and data.
Technical characteristics:
1.pre-freeze drying processing is in situ,put the material into the drying cabinet, it is automatic for the process of freezing and dring.
2.The machine is cascade refrigeration technology,imported compressor which is low noise,large
cooling capacity and high capacity of water capture to reduce the time of freeze drying.
3.Silicon oil is intermediate medium in the shelves for heating to Ensure drying material uniformity,
temperature discrepany is ≤1°C
4.The shelf temperature can be adjustable and control which is Easy for exploring of semi-work and production process
5.The square shelf is difficult for distortion, and easy for operation and cleaning.
6.LCD display designed as touch screen, it adopt PLC control system, can display all
important curves and data, human-computer interface can provide the user more information for relevant freeze drying process.
7.Cold trap and operation panel are made by stainless steel,corrosion-resistant and easy to clean
8.The inflation valve is optional,which can be filled with inert gas.
9.The cabinet door is with high transparent colorless organic glass, The material change process
can be easily observed during the operation through the transparent door.
10.The recorder and computer communication interface is optiona
| Speficication | SJIA-20F | SJIA-30F | SJIA-50F | SJIA-100F | |
| Shelf System | |||||
| 1 | shelf dimensions(mm) | 300x400 | 300x400 | 475 x 355 | 475x355 |
| 2 | No. of Shelves | 2+1 radiant | 3+1 radiant | 3+1 radiant | 6+1 radiant |
| 3 | Total shelf area(m2) | 0.24 | 0.36 | 0.51 | 1 |
| 4 | shelf clearance(mm) | 70-100 | |||
| 5 | MOC of the shelves | SS316L | |||
| 6 | Finish | pharma finish better than 220 Grit | |||
| 7 | Shelf temperature range | -50℃ to +70℃ | |||
| 8 | cooling time from 20C to -40C | 60min | |||
| 9 | shelf uniformity | ±1℃ | |||
| 10 | heater capacity | 1KW | 2KW | ||
| 11 | heating rate | Greater than 1℃ | |||
| 12 | shelf fluid | silicon Oil | |||
| 13 | fluid pump | WILO or Grundfos | |||
| 14 | stoppering | hydraulic stooer(optional) | |||
| CONDENSER | |||||
| 1 | Maxiumm low temperature | -80℃ | |||
| 2 | MOC of the condenser | SS 304 or SS316L | |||
| 3 | Finish | pharma finish better than 220 Grit | |||
| 4 | condenser capacity | 6 kg/24h | 7 kg/24h | 10 kg/24h | 15 kg/24h |
| 5 | condenser area(m2) | 0.45 | 0.54 | 0.66 | coil type |
| 6 | coolling time from 20C to -40C | 30min | |||
| 7 | defrost system | electric heater or hot gas | |||
| Vacuum | |||||
| 1 | ultimate vacuum | <0.01mbar | |||
| 2 | pump down time to 0.1mbar | 30 min | |||
| 3 | chamner leak rate | <20 ML/S | <20 ML/S | <25 ML/S | <30 ML/S |
| 4 | sensor type | inficon pirani | |||
| 5 | vaccum pump | LEYBOLD | LEYBOLD | LEYBOLD | LEYBOLD |
| chambers | |||||
| 1 | product chamber | rectangular chamber MOC SS304 or SS316L, | |||
| 2 | door | acrylic door door with opening to a max angle of 110° | |||
| 3 | sealing | split ring silicon ruber gasket | |||
| 4 | condenser chamner | round chamber with MOC SS304 or SS 318L | |||
| refrigeration system | |||||
| 1 | compressor | 1.25HP*2 | 1.5HP X2 | 2HP *2 | 4hP *2 |
| 2 | power unit | 2300w | 2800w | 3500w | 4500w |
| 3 | refrigerant | R507 & R23 | |||
| 4 | pressure control | danfos | |||
| 5 | Therm exp valve | danfos | |||
