Help CenterAir Source Heat Pump Water Heating Unit (LOW TEMP. Series)
Related Products
-
Air Source Heat Pump Water Heating UnitUS$ 300 - 8,000MOQ: 1 Set -
Air Source Heat PumpUS$ 900 - 3,000MOQ: 1 Set
-
10KW Air Source Heat Pump Hot Water Heater CE, Rohs, Sanyo CompressorUS$ 500 - 1,500MOQ: 5 Sets
-
MACON Domestic Hot Water Heat PumpUS$ 500 - 20,000MOQ: 5 Sets
-
MACON Air Source Heat PumpUS$ 500 - 50,000MOQ: 5 Sets
Specifications
heat pump1.Durable,Economical and high-efficiency2) Design flexibly,easy installation3)High efficient heat exchang, Safe useAir to water heat pump Air to water heat pump (LOW TEMP. series)
Product Details:
Heating capactity |
26000BTU/h~85000BTU/h |
COP |
4.20 |
Place of Origin |
Guangdong China |
Brand Name |
MACON |
Payment & Shipping Terms:
Delivery Time: |
30 Working Days |
Payment Terms: |
L/C,T/T |
Supply Abiity: |
30,000 Set/Sets per Year |
Detailed Product Description
This type is our LT series of air to water heat pump .LT series is specially designed for house heating in cold area .The evaporator is 30% bigger than normal ,which could ensure high efficiency and better performance in low ambient temperature .According to the test ,it could work safely in -15oC,and reach COP 4.0 in practical working condition .Special modular system design .The whole unit separated in 1, 2 and 3, respectively systems with separate compressors .Each system stays as a module, it can start and work separately .Benefit from this design ,the unit could have different output level according to the heating requirement .And also the modules could start one by one to lower the startup current.
R410a refrigerant is standard for this series, which also is helpful to get better performance in low temperature.
Standard unit composition:
1) Base frame and external panels made of galvanized powder coated steel.
2) Extremely compact structure, easy demountable for access.
3) High efficiency compressor with R410a Refrigerant.
4) Reverse cycle valve.
5) Intelligent controller and adjustment by quick mind microprocessor with possibility of remote control..
6) Water side equipped with stainless steel plate high efficiency exchanger.
7) Air exchanger (Fins-coil) with hydrophilic coating.
8) Automatic defrosting function included.
9) Thermostatic heating element for evaporator anti-frosting protection.
10) Thermostatic expansion valve.
11) General testing and operational test carried out for every unit before package in the factory.
Optional:
1) Energy recovery exchanger equipped inside, for producing sanitary hot water.
2) Available access to connect with external energy recovery system, such as MACON hot water heat pump.
3) Additional water storage tank.
Specification:
Heating capactity: 26000BTU/h~85000BTU/h
COP: 4.2 Cooling capacity: 26000BTU/h~68000BTU/h
EER: 2.85~3.0
Certification: CCC, CE, etc.
