Specifications
Air source All in one heat pump1.Function:domestic hot water
2.Shell: stainless steel
3.size:100/150/200/250/300L
4.CE,RoHS
Air source all in one heat pump, domestic hot water heat pump
| Model | MAHRWE(S) | 010ZCA1-200 | 010ZCA1P-250 | 015ZCA1-200 | 015ZCA1-300 |
| Application Number | 2--6 | 2--7 | 2--6 | 2--8 | |
| Water Volume | L | 200 | 200 | 200 | 300 |
| Rated Output Water | L/h | 75 | 75 | 100 | 100 |
| *Solar Specification | φ58×1800×20 | φ58×1800×20 | φ58×1800×25 | φ58×1800×30 | |
| *The Specification Of Solar Coil | m | φ22×20 | φ22×20 | φ22×20 | φ22×20 |
| Rated Heating Capacity | kW | 3.5 | 3.5 | 4.5 | 4.5 |
| BTU/h | 11900 | 11900 | 15400 | 15400 | |
| Rated Input Power | kW | 0.95 | 0.95 | 1.25 | 1.25 |
| Rated Input Current | A | 4.3 | 4.3 | 5.7 | 5.7 |
| Auxiliary Electric Heater | kW | 1.5 | 1.5 | 1.5 | 1.5 |
| Rated Temp.Of Water Output | °C | 55 | 55 | 55 | 55 |
| Max.Temp.Of Water Output | °C | 60 | 60 | 60 | 60 |
| Power Supply | V/PH/Hz | 220/1/50 | 220/1/50 | 220/1/50 | 220/1/50 |
| Compressor | Rotary | Rotary | Rotary | Rotary | |
| Compressor Qty | 1 | 1 | 1 | 1 | |
| Fan Qty | 1 | 1 | 1 | 1 | |
| Noise | dB(A) | 48 | 48 | 48 | 48 |
| PTR valve | inch | 1/2″ | 1/2″ | 1/2″ | 1/2″ |
| Hot Water Outlet | inch | 3/4″ | 3/4″ | 3/4″ | 3/4″ |
| Water Inlet | inch | 3/4″ | 3/4″ | 3/4″ | 3/4″ |
| Working Temp.Range | °C | -15~45 | -15~45 | -15~45 | -15~45 |
| Fan Direction | vertical | vertical | vertical | vertical | |
| Refrigerant Gas Type | R134a/R410A | ||||
| Max. Working Pressure Tank | MPa | 0.7 | 0.7 | 0.7 | 0.7 |
| Main Unit Net Dimensions(φ×H) | mm | φ700×1480 | φ700×1700 | φ700×1480 | φ700×1800 |
| Main Unit Shipping Dimensions(L/M/H) | mm | 800/700/1750 | 800/700/1850 | 800/700/1750 | 800/700/1950 |
| Net Weight | kg | 95 | 102 | 98 | 108 |
| Shipping Weight | kg | 115 | 122 | 118 | 128 |
1.Attractive appearance
Adopts streamline appearance, stainless steel shell design,combined with indoor decoration,more high-grade,long-life.
2.High efficient
Adopt Japanese brand high efficient compressor(Panasonic/Mitsubishi/Sanyo) and direct type coil heat exchanger,and use AC single inlet type centrifugal blower instead of normal fan blade, which make the air heat exchange greatly raised ,to make the COP more than 3.6.
3.Economic and practical
Using energy efficient compressors, low operating cost. Comprehensive power consumption is only 65% of the solar energy water heater, 25% of electric water heaters.
4.Safe and reliable
Separation from water and electricity, no produce exhaust,no combustion emissions to prevent leakage and gas poisoning. Integration design, fully welded closed ,without refrigerant pipe connections, more simple to installation and reliable.
5.Three-core design(Combination with three heat sources)
Heat pump can install with electric auxiliary heater or solar (optional) to assist the heater , so that the heat pump will more energy-saving and can work in any weather and at day and night .
6.Simple operation
Intelligent design, large-screen LCD display, easy operation, 30 ° c - 60° c free setting, cycle timing can be set on/off, with power failure momery function, automatic high-temperature sterilization (optional).
7.Wide application to save your money
This all in one heat pump has series of product with different volumes to meet different demands by ordinary
households, factory, school , hotels, restaurants, hospitals, beauty salons,laundries and so on , and it will
work in temperatures from as low as -10 to + 43 during day and night very efficiently.
