1.5kw wind generator energy details:
1.5kw wind generator energy features:
1.Carbon steel body, compact, safe.
2.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
3.Patented permanent magnet ac generator with special stator,effectively reduce torque, well match the wind wheel and generator, and ensure the performance of whole system.
4.Tail adopts mechanical yaw technique, making it survive storm and run safely.
5.With epoxy zinc rich primer and polyurethane anti-corrosion treatment,be ultraviolet-proof, acid rain resistant, salt resistant.
1.5kw wind generator energy technical data:
Model |
NE-1500L |
Rated power |
1500w |
Maximum power |
1700w |
Rated voltage |
48/96v |
Start-up wind speed |
2.5m/s |
Rated wind speed |
10m/s |
Survival wind speed |
45m/s |
Top net weight |
48kg |
Wheel diameter |
3.2m |
Number of blades |
3 |
Blades material |
reinforced glass fiber |
Generator type |
Three phase permanent magnet AC synchronous generator |
Magnet material |
NdFeB |
Generator case |
Casting aluminum alloy |
Control system |
Electromagnet/wind wheel yaw |
Speed regulation |
Tail furling |
Working temperature |
-40°C - 80°C |
Gross weight |
50kg |
Certificates |
CE, ISO14001, ISO 9001,TUV |
1.5kw wind generator energy application:
Package:
