Help CenterHigh Efficiency 10kw Wind Turbine With High Quality for Sell
Related Products
-
Wind Power Generator Type 2kw Wind GeneratorUS$ 725 - 920MOQ: 1 Piece -
Rated 100w Wind Generator on Sale Made in ChinaUS$ 164 - 253MOQ: 1 Set
-
High Efficiency Competitive Price 1500w Wind Turbine Made in ChinaUS$ 580 - 750MOQ: 1 Set
-
off Grid System 1000watt 48/96v Wind Power Turbine With Best Price Made in ChinaUS$ 480 - 650MOQ: 1 Set
-
1000W 48V Alternator Magnet Permanent Generator Wind Turbine Output 1KW Made in ChinaUS$ 420 - 600MOQ: 1 Piece
1.Carbon steel body, compact, safe.
2.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure.
3.Patented permanent magnet ac generator with special stator,effectively reduce torque.
4.Tail adopts mechanical yaw technique, making it survive storm and run safely.
5.With epoxy zinc rich primer and polyurethane anti-corrosion treatment,be ultraviolet-proof, acid rain resistant, salt resistant.
Real Picture of 10kw Wind turbine system
Production Process of 10kw wind turbine
10kw wind turbine Technical Data
Model |
NE-10k |
Rated power |
10kw |
Maximum power |
13kw |
Rated voltage |
220/240/380v |
Start-up wind speed |
3m/s |
Rated wind speed |
10m/s |
Survival wind speed |
45m/s |
Top net weight |
400kg |
Wheel diameter |
8.2m |
Number of blades |
3 |
Blades material |
Reinforced glass fiber |
Generator type |
Three phase permanent magnet AC synchronous generator |
Magnet material |
NdFeB |
Generator case |
Carbon steel |
Control system |
Electromagnet/wind wheel yaw |
Speed regulation |
Tail furling |
Working temperature |
-40°C - 80°C |
Design life |
20 y |
Certificates |
CE, ISO14001, ISO 9001,TUV |
Packing Way
FAQ
1. Q: Does installation Easy ?
A: Very easy, every customer can do it by themselves, we will supply all the components for installation and
very details installation manual.
2. Q: Does our wind is enough for a wind generator ?
A: As our wind generator can start running at low wind speed2.5m/s. so your average annual wind speed is more
than 5m/s then you can use it .
3. Q: Which model wind generator is suitable for me?
A: Please contact our sales with following points :
1. What appliance do you want to running by the system? How many watts are they and their working time .
2. Your annual wind speed .
3. What kinds of system do you want ? On-grid or off-grid
4. Q: Can I only buy parts not whole system?
A: Yes,for example you can manufacture tower in local , we can supply you tower drawing .
Any other questions ,please feel free to contact us .
