Specifications
Rated voltage:0.6/1kvConductor:AL/CU
Armor:steel tape,thin steel wire,thick steel wire
Sheath: PVC/PE
cable electric
APPLICATION This product is applicable to being fixedly laid on the transmission and distribution line of alternative current rating 50Hz and rated voltage up to 0.6/1.0 kV with the use for power transmission, which is applied to the range of distribution network, industrial equipments, etc.
This product is the normal used cable, not suitable for some special places, such as underwater, ship, nuclear station, etc.
The product has good performance on electrical characteristic, chemical resistance, such as acid resistance, alkali resistance and organic solvent resistance. The product can be laid on any head drop condition even vertically in any place, that is to say, the cable can be laid without limit on head drop.
TYPE OF PRODUCT
type |
Name of product |
Applicability and surroundings |
|
Copper core |
Aluminum core |
||
VV |
VLV |
PVC insulated PVC sheath power cable |
For laying indoors , in tunnel or cable trench, unable to bear external machan-inforces.Single-core cable in magnetic duct is not permissible |
VY |
VLY |
PVC insulated PE sheath power cable |
|
VV22 |
VLV22 |
PVC insulated steel tape armored PVC sheath power cable |
For laying indoors , in tunnel, cable trench, or direct in ground,able to bear external mechanical forces, but unable to bear large pulling force . |
VV23 |
VLV23 |
PVC insulated steel tape armored PE sheath power cable |
|
VV32 |
VLV32 |
PVC insulated thin steel-wire armored PVC sheath power cable |
For laying indoors , in tunnel, cable French, well or direct in ground,able to bear external mechanical forces, and certain force . |
VV33 |
VLV32 |
PVC insulated thin steel-wire armored PE sheath power cable |
|
VV42 |
VLV42 |
PVC insulated thin steel –wire armored PVC sheath power cables |
|
VV43 |
VLV43 |
PVC insulated thin steel –wire armored PE sheath power cables |
|
COMPANY & WORKSHOP
PRODUCTION EQUIPMENT
TEST EUIPMENT
FAQ
