Flowmeter Transducer LGSY-50/80

Flowmeter Transducer LGSY-50/80 thumbnail-1
Flowmeter Transducer LGSY-50/80 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
LGSY
Model Number:
LGSY-50/80
Contact Supplier Request Quote Chat Now
Xian Wellwork Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name LGSY
Model Number LGSY-50/80

Specifications

1.Flowmeter Transducer is High Quality,
2.No Pressure Lose
3.Long Lifetime
4.High Accuracy

Flowmeter Transducer LGSY-50/80

Virtually No Pressure Loss

There is no moving part to down the pressure.



Corrosion protection, abrasion resistant

The surface was painting with PU coating



High accuracy, Stable performance

The struction is test strictly to ensure the high accuracy and stability



High level of anti-vibration and anti-jamming, wide measuring dimensions

polyurethane was injected to the sensor boy to ensure the sensor has good capability



Multi-Output Interface4~20mA, Pulse, Alarm Outputs, RS-485 and Modbus Communication



Technical data

Nominal Meter Size
10 to 200mm



Liquid Pressure (MPa)
1.0, 1.6, 2.5, 4.0, 16, 25, 35, 42



Accuracy
 ±0.5%, ±1% (upon req.)



Minimum Conductivity
5μs/cm



Electrode Material
SST 316L (standard), Hastelloy, Tantalun, titanium, Tungsten Carbide (upon req.)



Fluid Temperature
 -25 to 65 (-13 to 149)
 -25 to 140(-13 to 284)(opt.)



Liner
 CR, FEP, PTFE, PFA



Relative Humidity
≤85%



Ambient Temperature
-30 to 60 (-22 to 140)

Current Output
0 to 10mA or 4 to 20mA



Frequency Output
0 to 5000Hz with photoelectric isolation



Pulse Output
Adjustable from 0.001 to 1000 Ltr/Pulse



Alarm Output
Upper Alarm-ALMH, Lower Alarm-ALML with photoelectric isolation
Upper Alarm-ALMH, Lower Alarm-ALML with photoelectric isolation



Communications
RS-232 without galvanic isolation
RS-485 with galvanic isolation, MODBUS.



Supply Power
85 to 250VAC (45 to 63Hz)
16 to 36VDC



Power
S10W/AC, S7.5W/DC
