2013 Low Price Electromagnetic Flow Meter

2013 Low Price Electromagnetic Flow Meter thumbnail-1
2013 Low Price Electromagnetic Flow Meter photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
LGSY
Model Number:
LGDC Series
Contact Supplier Request Quote Chat Now
Xian Wellwork Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xi'an
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name LGSY
Model Number LGDC Series

Specifications

1.High accuracy
2.Threaded type electromagnetic Flowmeter ideal for conductive liquids

LGDC Series Electromagnetic flowmeter

Detailed Product Description

DN 50mm
Liner PTFE /Rubber
Signal output 4-20mA, pulse
Type electromagnetic flowmeter

Specifications


Nominal diameter range DN (mm)
 Pipeline PTFE lining:
      10,15,20,25,32,40,50,65,80,100,125, 150,200,250,300,350,400.450,500,600
 Pipe rubber lining:
      40,50,65,80,100,125,150,200,300,350,400,500,600,800,1000,1200
 Note: Special specifications can be customized

Flow direction


      positive and negative, the net flow,
      Turndown Ratio: 150:1
      Repeatability: ± 0.1% of measured value
Accuracy: pipeline: 0.5
Measured medium temperature:
      ordinary rubber lining: -20 ~ +60 °C
      high temperature rubber lining: -20 ~ +90 °C
      PTFE lining: -30 ~ +100 °C
      high temperature vinyl lining: -30 ~ +180 °C
Rated working pressure: pipeline
      DN10-DN65: ≤ 2.5Mpa,
      DN80-DN150: ≤ 1.6Mpa,
      DN200-DN1200: ≤ 1.0Mpa
Flow measurement range:
      speed range convection flow measurement range is 0.3-15m / s

Explosion Proof:Exd(ib)ibqIIBT5 (with AMC3100 only)



For more information,please contact us freely without any hesitation,Thank you.

We can provide Super quality,comptitive price and Best service for you at any times.



Your satifaction is our pursuit!

 Xi'an wellwork Co.,Ltd.
