E+H High Quality Differential Pressure Transmitter With Ceramic Sensor Deltabar S PMD70

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Germany

Brand Name:

E+H

Model Number:

Deltabar S PMD70

Xian Wellwork Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xi'an

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Germany

Brand Name E+H

Model Number Deltabar S PMD70

Specifications

1.Good reproducibility and long-term stability
2.Quick commissioning thanks to quick setup menu
3.Menu-guided operation

E+H

Differential pressure transmitter Deltabar S PMD70

Differential pressure transmitter with ceramic sensor

Overload-resistant and function-monitored, Communication via HART, PROFIBUS PA or FOUNDATION Fieldbus

Benefits:

Very good reproducibility and long-term stability
High reference accuracy: up to ±0.075%, as PLATINUM version: ±0.05%
Turn down 100:1, higher on request
Used for flow and differential pressure monitoring up to SIL3, certified to IEC 61508 by TÜV SÜD
HistoROM^®/M-DAT memory module
Function-monitored from the measuring cell to the electronics
Continuous modularity for differential pressure, hydrostatic and pressure (Deltabar S, Deltapilot S, Cerabar S), e.g.
- replaceable display
- universal electronics for pressure and differential pressure
Quick commissioning thanks to quick setup menu
Menu-guided operation
Extensive diagnostic functions

The Deltabar S differential pressure transmitter is used for the following measuring tasks:

Flow measurement (volume or mass flow) in conjunction with primary elements in gases, vapours and liquids
Level, volume or mass measurement in liquids
Differential pressure monitoring, e.g. of filters and pumps
International usage thanks to a wide range of approvals

Specification of Deltabar S PMD70:

Measure Principle	Differential pressure
Characteristic /Application	Digital transmitter with ceramic measuring diaphragms Modular transmitter Long term stability Enhanced safety via self diagnostic functions Secondary process barrier
Supply / Communication	4...20 mA HART: 10,5...45V DC Ex ia: 10,5...30V DC PROFIBUS PA / FOUNDATION Fieldbus: 9...32V DC
Accuracy	0,075% "PLATINUM" 0,05%
Long term stability	0,05% of URL/year
Ambient temperature	-20°C...85°C (-4°F...185°F)
Process temperature	-20°C...85°C (-4°F...185°F)
Process pressure absolute / max. overpressure limit	150 bar (2250psi)
Pressure measuring range	25mbar...3 bar (0.36psi...45psi)
Main wetted parts	Ceramic Alloy C276 316L Monel Tantalum
Process connection	1/4-18NPT RC1/4"
Max. measurement distance	30m (98ft)H2O
Output	4...20 mA HART PROFIBUS PA FOUNDATION Fieldbus
Certificates / Approvals	ATEX FM CSA NEPSI IECEx SIL GL marine WHG/ Overfill prevention EN10204-3.1
Options	HistoROM/M-Dat 4-line digital display SS- or Aluminiumhousing Separate housing
Application limits	Measuring cell: Ceramic
