Help Center4 Cores G652D Indoor Fiber Optical Cable/ Distribution Cable
Related Products
1. GYXTW-4
The performance of cabled single mode optical fiber (ITU-T Rec. G.652D)
2.1: Color sequence
No. |
1 |
2 |
3 |
4 |
5 |
6 |
Color |
Blue |
Orange |
Green |
Brown |
Gray |
Natural |
No. |
7 |
8 |
9 |
10 |
11 |
12 |
Color |
Red |
Black |
Yelllow |
Violet |
Pink |
Aqua |
2.2 Sheath Printing:
XXXXXX |
: Brand |
GYFXTY |
: Type |
XXB1 |
: Fiber quantity and mode |
2009XXXX |
: Production date |
XXXXM |
:Meter |
2.3 Structure and parameter
Fiber quantity |
Tube diameter |
Steel wire diameter |
Sheath thickness (Nominal*) |
Overall diameter (Nominal**) |
mm |
mm |
mm |
mm |
|
4 |
2.1 |
0.9 |
1.6 |
7.6 |
* The nominal sheath thickness may vary by ±0.2mm.
** The nominal outer diameter and height may vary by ±0.3mm.
|
structure: Centre PBT—casing, two high-strength steel casing parallel to the uniform on both sides, outsourcing steel-bonded polyethylene sheath. | ||||
quantity of fibers:2~12 | ||||
outer diameter(mm):7.5-9.2 | ||||
approximated cable weight(kg/km):85 | ||||
Laying mode:Aerial, Duct | ||||
operating temperature:-40°C~+60°C | ||||
|
Application: Long distance and interoffice communication | ||||
features: |
1. Two-wire strengthen roots, anti-lateral pressure excellent performance, and a bullet tensile properities. . |
|||
|
2. Double coated strip tide, and has lateral pressure. | ||||
The main mechanical properties: |
Allow tensile force(N) |
short-term |
1500 |
|
long-term |
600 |
|||
Allow squash Force(N/100mm) |
short-term |
1000 |
||
long-term |
300 |
|||
min bend radius)(D:mm) |
Static |
12.5D |
||
Dynamic |
25D |
|||
