JDF5060XLCJ

Name: JDF5060XLCJ
Brand: JMC refrigerator
SKU: 113965779

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

JMC refrigerator

Model:

JDF5060XLCJ

Place of Origin:

China

Hubei Qixing Vehicle-Body Limited Company

Payment & Shipping

Payment Methods:

Port of Shipment:

wuhan/shanghai/

Delivery Detail:

Delivery time depends on order quantity.

Brand Name JMC refrigerator

Model JDF5060XLCJ

Place of Origin China

Transmission Type Manual

Condition New

Emission Standard Euro 3

Fuel Type Diesel

Dimensions (L x W x H) (mm) 5995X1950X2900

Box Dimensions (L x W x H) (mm) 4095mmx1745mmx 1775mm

Temperature Range -18~+20

Gross Vehicle Weight 6630

Product Description

CLW5061XLC3
Item	Parameter	Unit
Vehicle model	CLW5061XLC3 refrigerator truck
Chassis model	EQ1060TJ20D3
Emission standard	Euro3
Overall dimension	5995×2020×3000	mm
Body internal dimension	4000×1850×1800
Wheel base	3300
F/R track base	1506/1466
F/R overhang	1032/1663
GVW	6495	Kg
Mass in working order	3500
Rated loading capacity	2800/2865
Axle- load	2385/4110
Operation control system	Electrically hydraulic control
Approach/departure	19/10	°
Max speed	90	Km/h
Tire specification	7.00-16/6.50-16
Traction system	4X2
Number of tires	6
Number of axles	2

More information:

Product Name	13cbm Refrigerated Truck
Chassis Manufacturer	Dongfeng Automobile Co., Ltd.
Transmission Model	Manual		Emission standards		Euro 3
*Item*	*parameters*	*Unit*	*Item*		*parameters*	*Unit*
Total Mass	6495	(kg)	Overall dimensions (LWH)		5995×2020×3000	(mm)
Rated Payload	2800	(kg)	Compartment Size		4000×1850×1800	(mm)
Curb Weight	3500	(kg)	Max speed		90	(Km/h)
F/R suspension	1032/1663	mm	Approach/Departure angle		19/10	(°)
Chassis	Chassis Model			EQ1060TJ20D3
	Wheel base (mm)			3300
	Tire specification (mm)			7.00-16,6.50-16,7.00R16,6.50R16
	Front tread			1506
	Rear tread			1466
	Fuel Type			Diesel
	Horse Power(hp)			90
	Number of tires			6
	Drive Wheel			4*2
	Cab			As standard 3 people accepted inside, whole metal- enclosed
Engine parameters	Engine Model			YC4F90-30
	Exhaust (ml)			2659
	Engine Power (ml/kw)			66
Engine	Guangxi Yuchai Machinery Co., Ltd.
Vehicle Description Section	Install the side door compartments. According to the chassis choose the cab. Optional side door. Protective equipment materials:Q235. Rear protection from the ground height is 450mm.
Warranty	12 month from the supply date.
