Fiberglass High Temperature Sleeve
US$ 0.0272 - 0.736
MOQ: 10000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
strong
Model Number:
0.5-32mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fiberglass Busbar Insulation SleevesUS$ 0.0272 - 0.736MOQ: 10000 Meters -
2.5kv PVC Fiberglass SleevesUS$ 0.0104 - 2.08MOQ: 10000 Meters
-
4.0kv PVC Fiberglass SleevesUS$ 0.0104 - 2.08MOQ: 10000 Meters
-
Electrical Wire SleeveUS$ 0.0272 - 0.736MOQ: 10000 Meters
-
Pvc Fiberglass SleevesUS$ 0.0105 - 2.08MOQ: 10000 Meters
Place of Origin
Shandong, China
Brand Name
strong
Model Number
0.5-32mm
Type
Insulation Sleeving
Material
Fiberglass
Application
High Voltage
Rated Voltage
1.5-10KV
Tensile Strength
HIGH
fiberglass busbar insulation sleeves
We could provide you DSG with different voltages: DSG-1(1.5KV), DSG-2(2.5KV),DSG-3(4KV),DSG-4(7KV),DSG-5(10KV)
Thermal Class:H
Color: we could provide you the color as your requirements.
Application: Silicone fiberglass sleeving is widely used in wiring insulation and mechnical protection for electric motors, transformers and electrical instruments.
The following is some specifications:
| Inside diameter(mm) | Tolerance(mm) | Wall Thickness(mm) | ||||
| DSG-1 | DSG-2 | DSG-3 | DSG-4 | DSG-5 | ||
| 0.5-2.5 | +0.3 -0.0 | 0.40±0.12 | 0.41±0.12 | 0.43±0.12 | 0.47±0.12 | 0.51±0.12 |
| 3.0-4.5 | 0.46±0.13 | 0.408±0.13 | 0.51±0.13 | 0.54±0.13 | 0.59±0.13 | |
| 5.0-8.0 | 0.50±0.15 | 0.52±0.15 | 0.55±0.15 | 0.59±0.15 | 0.64±0.15 | |
| 9.0-12 | 0.60±0.18 | 0.62±0.18 | 0.66±0.18 | 0.70±0.18 | 0.75±0.18 | |
| 14.0-16.0 | 0.62±0.18 | 0.65±0.18 | 0.80±0.18 | 0.85±0.18 | 0.96±0.18 | |
| 18.0-25.0 | 0.64±0.18 | 0.66±0.18 | 0.82±0.18 | 0.86±0.18 | / | |
| 26.0-32.0 | 0.66±0.18 | 0.68±0.18 | 0.88±0.18 | 0.92±0.18 | ||
We also could produce it according to the customer's requirement.
